HPE ProLiant DL345 Gen11 9115 3.2GHz 16c 1P 2x32GB-R 8SFF MR416i-p 2x480GB SSD 2x1000W PS EU Server
- Brand
- Hewlett Packard Enterprise
- Product code
- P81839-425
- SKU
- KE0UCSN565VVU
- EAN/GTIN
- 0190017795713
- This HPE pre built server includes the following:
- 2x P64985-B21 = HPE 32GB 1x32GB Dual Rank x8 DDR5-6400
- 2x P40497-B21 = HPE 480GB SATA 6G Read Intensive SFF (2.5in) Basic Carrier Multi Vendor SSD
- 2x P03178-B21 = HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit
Product Info
The HPE ProLiant DL345 Gen11 server is a scalable 2U 1P solution that delivers exceptional compute performance and large capacity storage options at 1P economics. Powered by 4th Generation AMD EPYC Processors with up to 96 cores, increased memory bandwidth, high-speed PCIe Gen5 I/O and EDSFF storage, up to 20LFF/ 34SFF, and up to 4 GPUs at the front, this server is a superb single-socket 2U solution for your data-intensive workloads. Enhanced security features with the HPE silicon root of trust are built into the firmware, creating a digital fingerprint for the AMD Secure Processor to validate safe operation before boot. The HPE DL345 Gen11 server provides impressive storage performance and options for dataintensive workloads like software-defined storage, video transcoding, and virtualized apps.
Description
Efficient management
Equipped with Integrated Lights-Out 6 remote management controller and IPMI 2. 0, this server simplifies and streamlines server setup, health monitoring, and management, allowing for reduced operational costs and improved server uptime.
High-speed performance
Powered by AMD EPYC processor and supported by HPE SmartMemory with a speed of 4800 MHz, the DL345 Gen11 ensures high-speed performance and reliability, making it suitable for demanding workloads.
Flexible storage options
With 8 hot-swap server storage bays and a RAID storage controller featuring a 4 GB buffer size, this server offers flexible storage options and enhanced data protection, suitable for various storage requirements.
Advanced connectivity
Featuring a range of networking protocols including Ethernet, Fast Ethernet, and Gigabit Ethernet, along with PCIe 5. 0 x16 expansion slots, this server provides advanced connectivity options for high-speed data transfer and networking flexibility.
Energy-efficient design
ENERGY STAR certified and compliant with multiple environmental standards, the DL345 Gen11 server combines performance with energy efficiency, contributing to lower operating costs and a reduced environmental footprint.
| Monitor | |
|---|---|
| Monitor Type | None. |
| Processor / Chipset | |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| CPU Upgradability | Upgradable |
| Clock Speed | 2.6 GHz |
| Max Turbo Speed | 4.1 GHz |
| Number of Cores | 16-core |
| CPU | AMD EPYC 9115 |
| Processor Main Features | 125W TDP |
| Power | |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Device Type | Power supply - hot-plug |
| Power Provided | 1000 Watt |
| Power Redundancy | Yes |
| Voltage Required | AC 100-120/200-240 V |
| Power Redundancy Scheme | 1+1 |
| 80 PLUS Certification | 80 PLUS Titanium |
| General | |
| Type | Server |
| Hot-Swap Bays Qty | 8 |
| Built-in Devices | Led panel |
| Server Scalability | 1-way |
| Product Form Factor | Rack-mountable - 2U |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Localisation | Region: Europe, Middle East, Africa |
| Environmental Parameters | |
| Min Operating Temperature | 10 °C |
| Max Operating Temperature | 35 °C |
| Humidity Range Operating | 8 - 90% RH (non-condensing) |
| Dimensions & Weight | |
| Width | 44.8 cm |
| Height | 8.75 cm |
| Depth | 64.6 cm |
| Weight | 16.04 kg |
| Cache Memory | |
| Cache Per Processor | 64 MB |
| Installed Size | L3 Cache - 64 MB |
| Graphics Controller | |
| Video Memory | 16 MB |
| Video Interfaces | VGA |
| Sustainability Information | |
| ENERGY STAR Version | 4.0 |
| ENERGY STAR Certified | Yes |
| Storage Controller | |
| Channel Qty | 16 |
| Buffer Size | 8 GB |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
| Type | 1 x RAID - PCIe 4.0 x8 |
| Controller Interface Type | Serial ATA-600 / SAS 3.0 / PCI Express (NVMe) |
| Storage Controller Name | HPE MR416i-p Gen11 SPDM |
| Dimensions & Weight (Shipping) | |
| Shipping Height | 27 cm |
| Shipping Width | 60 cm |
| Shipping Depth | 91.77 cm |
| Networking | |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Ethernet Ports | 4 x Gigabit Ethernet |
| Features | Wake on LAN (WoL), PXE support |
| Ethernet Controller | Broadcom BCM5719 |
| Interface (Bus) Type | Open Compute Project mezzanine (OCP) 3.0 |
| Remote Management Controller | Integrated Lights-Out 6 |
| Remote Management Protocol | IPMI 2.0, SNMP 3 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labour - 3 years - on-site - response time: next business day |
| RAM | |
| Rated Memory Speed | 3200 MHz |
| Effective Memory Speed | 3000 MHz |
| Configuration Features | 2 x 32 GB |
| Form Factor | DIMM 288-pin |
| Slots | 12 (Total) / 10 (empty) |
| Technology | DDR5 SDRAM |
| Installed Size | 64 GB (installed) / 3 TB (max) |
| Features | HPE SmartMemory, registered |
| Hard Drive | |
| Type | SSD |
| Capacity | 2 x 480 GB |
| Interface Type | SATA 6Gb/s |
| Features | HPE Multi Vendor, Read Intensive |
| Optical Storage | |
| Type | No optical drive |
| Expansion / Connectivity | |
| Bays | 8 (total) / 6 (free) x hot-swap 2.5" SFF |
| Interfaces | 1 x HPE iLO (1 in front) (service port)5 x USB 3.2 Gen 1 (1 front, 2 rear, 2 internal)1 x VGA4 x LAN (Gigabit Ethernet) |
| Slots | 2 (total) / 2 (free) x PCIe 5.0 x16 - half-length, full-height (x16 mode)2 (total) / 1 (free) x Open Compute Project mezzanine (OCP) 3.0 |
| Operating System / Software | |
| Software | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download) |
| OS Certified | Microsoft Windows Server 2019, Microsoft Windows Server 2022, Red Hat Enterprise Linux 8.6, Red Hat Enterprise Linux 9.0, SUSE Linux Enterprise Server 15 SP4, VMware ESXi 7.0 update 3, VMware ESXi 8.0 |
| Miscellaneous | |
| Manufacturer Selling Program | HPE Smart Choice |
| Included Accessories | 6 x standard fans, HPE Easy Install Rail 2 Kit, HPE standard heatsink |
| Compliant Standards | WEEE, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, ACPI 6.1, UEFI 2.7, SMBIOS 3.1, Redfish API, AES, Triple DES, UEFI Class 3, Active Directory v1.0, APML 1.0 |
