Qnap

General

Depth 23.5 cm

Height 17 cm

Width 18 cm

Built-in Devices Led panel

Installed Devices / Modules Qty 0 (installed) / 4 (max)

Total Storage Capacity 0 GB

Device Type NAS server

Host Connectivity 2.5 Gigabit Ethernet

Weight 3 kg ()

Localisation Czech, Chinese (traditional), Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Brazilian Portuguese, Romanian, Russian, Spanish, Swedish, Thai, Turkish

Expansion / Connectivity

Expansion Bays 4 (total) / 4 (free) x hot-swap - 2.5" / 3.5"

Expansion Slots 2 (total) / 0 (free) x M.2 2280

Interfaces 2 x 2.5 Gigabit Ethernet - RJ-452 x USB 2.0 - Type A2 x USB 3.2 Gen 2 - Type A2 x HDMI output

Manufacturer Warranty

Service & Support Limited warranty - 3 years

Networking

Performance Concurrent connections (CIFS): 1500Maximum number of storage pool: 128Maximum number of volume: 128Maximum volume size: 250 TBMaximum pool size: 308 TBMaximum LUN size: 250 TBMaximum number of targets LUN: 256Minimum snapshot interval: 5 minMaximum FTP connection: 1024Local user account: 4096Local group account: 512Domain user/group account: 200000Log recording: 3000 events per secondVirtual hosts: 32

Data Link Protocol 10Mb LAN, 100Mb LAN, 1GbE, 2.5GbE

Network / Transport Protocol CIFS, iSCSI, QuFTP, IPv6, IPv4, DDNS, PPTP, L2TP, IPSec, WireGuard, QBelt, OpenVPN

Remote Management Protocol TFTP, SNMP 2, SNMP 3, SSH, Telnet, HTTP, HTTPS, RADIUS

Network Services Compatibility Apple File Protocol (AFP), Microsoft CIFS, FTP, Network File System v3 (NFS v3), Network File System v4 (NFS v4), SFTP, HTTP, HTTPS

Encryption Algorithm AES-NI, SSL, TLS, 256-bit AES, FIPS 140-2, TLS 1.0, TLS 1.1, TLS 1.2, TLS 1.3

Features Floating point unit, built-in hardware transcoding, SSD cache acceleration support, WOL, Jumbo Frames support, Storage Pool, SED Storage Pool, JBOD Expansion, VJBOD Cloud, iSCSI service, file-based iSCSI LUN, block-based iSCSI LUN, LUN masking, LUN mapping, WWPN Aliases Import/Export, FC Port Group, FC Port Binding, MPIO, online LUN capacity expansion, LUN snapshot, LUN snapshot replication and clone, auto tiering, RAID Group, RAID Level Migration, RAID Expansion, Storage Pool Expansion, RAID Hot Spare, RAID Sync/Rebuild/Scrubbing, Disk, Enclosure Locate, Disk S.M.A.R.T. Scan, Disk S.M.A.R.T. Data Migration, SSD trim, SSD life estimation, Disk Roaming, Disk Standby, Volume Snapshot, Snapshot Retention Policy, Self-serve Snapshot Recovery, Application Consisted Snapshot, Snapshot Full Clone, Snapshot Replica / Vault, SSD read-only Cache, SSD read-write cache, SSD write-only cache, SSD profiling tool, External Device Management, SSD Cache RAID, MTP, FTP server, FXP support, Object Storage, file station, domain security, Domain Controller, Windows ACL, user quota managerment, group quota, folder quota, home folder, Resource Monitor, Network Recycle Bin, schedule on/off, Virtual Switch, port trunking, VLAN support, DHCP server, security counselor, malware remover, 2-step verification, Allow/Deny List, Access Protection, Service binding, WebDAV server support, Qsync, HybridMount, Windows ODX, hybrid backup sync, network drive mount, Hyper Data Protector, Boxafe, Qsirch, QuMagie, LDAP server, HD Station, SQL Server, Qfiling, QmailAgent, QuWAN, DA Driver Analyzer, Q'center (NAS CMS)

Miscellaneous

Cables Included 1 x network cable

Compliant Standards FIPS 140-2

Security Slot Type Kensington security slot

Features 120mm cooling fan, security lock slot (cable lock sold separately), Secure Erase, Smart Fan, built-in firewall

Included Accessories Power cable, 2 x flat head screws (for M.2 SSD), 12 x flat head screws (for 2.5" HDD), 16 x flat head screws (for 3.5" HDD), 2 x drive tray keys

Power

Power Provided 90 Watt

Voltage Required AC 100-240 V

Power Device External power adapter

Power Consumption Operational 33.88 Watt

Software / System Requirements

Storage Operating System QNAP QTS 5.0.0

OS Required Apple MacOS X 10.10 or later, Ubuntu Linux 14.4 (64-bit), CentOS 7.0, Red Hat Enterprise Linux 6.6, SuSE Linux 12 or later, IBM AIX 7, Microsoft Windows 7 / 8 / 10 / 11, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, Microsoft Windows Server 2019, Oracle Solaris 10 or later, QNAP QVR Pro, QNAP QVR Elite

Software Included IronWolf Health Management, vSphere plug-in for VMware, Windows Update Agent, McAfee AntiVirus, QNAP Virtualization Station

Environmental Parameters

Min Operating Temperature 0 °C

Max Operating Temperature 40 °C

Humidity Range Operating 5 - 95% RH (non-condensing)

Storage Controller

Type RAID

RAID Level RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, JBOD, RAID 60

Interface Type SATA 6Gb/s

Processor / Memory

Max Supported Qty 1

Flash Memory Installed 4 GB

Max Turbo Speed 2.6 GHz

Number of Cores Quad-Core

RAM 8 GB (installed) / 8 GB (supported)

Processors Installed 1 x Intel Celeron J6412

Dimensions & Weight (Shipping)

Shipping Weight 4.3 kg
