WD Ultrastar DC HC590

0F59375 - 829686009158

DC HC590 26TB 512MB SAS 512E SE P3

Brand: Western Digital
Product code: 0F59375
SKU: 3J84747NPCV6D
EAN/GTIN: 829686009158

Hard drive
Data Centre
encrypted
26 TB
internal
3.5"
SAS 12Gb/s
7200 rpm
buffer: 512 MB
Self-Encrypting Drive (SED)
Weight: 0.68 KG

€1401.62 (Inc. VAT)

Sold Out

(Delivery 2-4 working days)

Product Info

The WD Ultrastar DC HC590 is designed for data center applications, offering a substantial capacity of 26 TB for extensive data storage needs. It operates efficiently with an average latency of just 4.16 ms and provides data transfer rates of 1.2 GBps, making it suitable for high-demand environments. The drive is built to endure a variety of operational conditions, with a minimum operating temperature of 5 °C and a maximum of 60 °C, ensuring reliable performance in diverse settings. HelioSeal technology maximizes capacity and efficiency, while features like Dynamic Fly Height and ArmorCache technology enhance data integrity and performance.

This internal hard drive supports 24x7 operation with an MTBF of 2,500,000 hours, ensuring sustained availability. The implementation of self-encrypting features ensures data security, while advanced formats 512e and 4Kn accommodate various system requirements. With non-recoverable errors rated at 1 per 10^15, users can trust in the reliability of the WD Ultrastar DC HC590 for critical data storage.

Description

High-capacity storage

With 26 TB of storage space, this hard drive is ideal for environments requiring significant data retention and management.

Robust performance

The internal data rate of 302 MBps and data transfer rate of 1. 2 GBps contribute to quick data access and processing.

Enhanced durability

Featuring a minimum storage temperature of -40 °C and a maximum storage temperature of 70 °C, this drive is built to withstand various environmental conditions.

Advanced data protection

The self-encrypting feature safeguards sensitive information, ensuring that data remains secure at all times.

Vibration resilience

Equipped with Rotational Vibration Safeguard, this hard drive minimizes the impact of vibration on performance, contributing to its reliability.

Specifications

General

Buffer Size 512 MB

Form Factor 3.5"

Hardware Encryption Yes

Weight 670 g

Width 101.6 mm

Height 26.1 mm

Device Type Hard drive - internal

Capacity 26 TB

Interface SAS 12Gb/s

Depth 146.7 mm

Features HelioSeal, advanced format 512e, advanced format 4Kn, OptiNAND technology, ArmorCache Technology, 24x7 availability, Energy-Assisted Magnetic Recording (EAMR), Rotational Vibration Safeguard (RVS), Dynamic fly height technology, Conventional magnetic recording (CMR), self-encrypting

Manufacturer Warranty

Service & Support Limited warranty - 5 years

Power

Power Consumption 8.4 Watt (random read/write)5.6 Watt (idle)

Environmental Parameters

Max Operating Temperature 60 °C

Min Operating Temperature 5 °C

Max Storage Temperature 70 °C

Min Storage Temperature -40 °C

Shock Tolerance (operating) 40 g @ 2 ms half-sine wave

Vibration Tolerance (operating) 0.7 gRMS @ 5-500 Hz

Vibration Tolerance (non-operating) 1.04 gRMS @ 2-200 Hz

Shock Tolerance (non-operating) 200 g @ half-sine wave

Performance

Average Latency 4.16 ms

Spindle Speed 7200 rpm

Drive Transfer Rate 1.2 GBps (external)

Drive Class Data Centre

Internal Data Rate 302 MBps

Reliability

Non-Recoverable Errors 1 per 10^15

24x7 Operation Yes

Load / Unload Cycles 600,000

MTBF 2,500,000 hours

Expansion & Connectivity

Compatible Bay 3.5"

Interfaces 1 x SAS 12 Gb/s
