DC HC590 26TB 512MB SAS 512E SE P3
- Brand
- Western Digital
- Product code
- 0F59375
- SKU
- 3J84747NPCV6D
- EAN/GTIN
- 829686009158
- Hard drive
- Data Centre
- encrypted
- 26 TB
- internal
- 3.5"
- SAS 12Gb/s
- 7200 rpm
- buffer: 512 MB
- Self-Encrypting Drive (SED)
- Weight: 0.68 KG
Product Info
The WD Ultrastar DC HC590 is designed for data center applications, offering a substantial capacity of 26 TB for extensive data storage needs. It operates efficiently with an average latency of just 4.16 ms and provides data transfer rates of 1.2 GBps, making it suitable for high-demand environments. The drive is built to endure a variety of operational conditions, with a minimum operating temperature of 5 °C and a maximum of 60 °C, ensuring reliable performance in diverse settings. HelioSeal technology maximizes capacity and efficiency, while features like Dynamic Fly Height and ArmorCache technology enhance data integrity and performance.
This internal hard drive supports 24x7 operation with an MTBF of 2,500,000 hours, ensuring sustained availability. The implementation of self-encrypting features ensures data security, while advanced formats 512e and 4Kn accommodate various system requirements. With non-recoverable errors rated at 1 per 10^15, users can trust in the reliability of the WD Ultrastar DC HC590 for critical data storage.
Description
High-capacity storage
With 26 TB of storage space, this hard drive is ideal for environments requiring significant data retention and management.
Robust performance
The internal data rate of 302 MBps and data transfer rate of 1. 2 GBps contribute to quick data access and processing.
Enhanced durability
Featuring a minimum storage temperature of -40 °C and a maximum storage temperature of 70 °C, this drive is built to withstand various environmental conditions.
Advanced data protection
The self-encrypting feature safeguards sensitive information, ensuring that data remains secure at all times.
Vibration resilience
Equipped with Rotational Vibration Safeguard, this hard drive minimizes the impact of vibration on performance, contributing to its reliability.
| General | |
|---|---|
| Buffer Size | 512 MB |
| Form Factor | 3.5" |
| Hardware Encryption | Yes |
| Weight | 670 g |
| Width | 101.6 mm |
| Height | 26.1 mm |
| Device Type | Hard drive - internal |
| Capacity | 26 TB |
| Interface | SAS 12Gb/s |
| Depth | 146.7 mm |
| Features | HelioSeal, advanced format 512e, advanced format 4Kn, OptiNAND technology, ArmorCache Technology, 24x7 availability, Energy-Assisted Magnetic Recording (EAMR), Rotational Vibration Safeguard (RVS), Dynamic fly height technology, Conventional magnetic recording (CMR), self-encrypting |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Power | |
| Power Consumption | 8.4 Watt (random read/write)5.6 Watt (idle) |
| Environmental Parameters | |
| Max Operating Temperature | 60 °C |
| Min Operating Temperature | 5 °C |
| Max Storage Temperature | 70 °C |
| Min Storage Temperature | -40 °C |
| Shock Tolerance (operating) | 40 g @ 2 ms half-sine wave |
| Vibration Tolerance (operating) | 0.7 gRMS @ 5-500 Hz |
| Vibration Tolerance (non-operating) | 1.04 gRMS @ 2-200 Hz |
| Shock Tolerance (non-operating) | 200 g @ half-sine wave |
| Performance | |
| Average Latency | 4.16 ms |
| Spindle Speed | 7200 rpm |
| Drive Transfer Rate | 1.2 GBps (external) |
| Drive Class | Data Centre |
| Internal Data Rate | 302 MBps |
| Reliability | |
| Non-Recoverable Errors | 1 per 10^15 |
| 24x7 Operation | Yes |
| Load / Unload Cycles | 600,000 |
| MTBF | 2,500,000 hours |
| Expansion & Connectivity | |
| Compatible Bay | 3.5" |
| Interfaces | 1 x SAS 12 Gb/s |
