S-Series 65" 4k IR LED Interactive Displ
- Brand
- AVOCOR
- Product code
- AVS-6510
- SKU
- AGYSUQI8FDM9I
- 65" Diagonal Class S Series LED-backlit LCD display
- interactive
- with touchscreen (multi touch)
- Android
- 4K UHD (2160p) 3840 x 2160
- direct-lit LED
- Weight: 48.00 KG
Product Info
The Avocor S Series is a part of Avocor's portfolio, designed to elevate educational environments, combining sleek design with advanced touch technology. Ideal for classrooms, lecture halls, and hybrid learning settings, the S Series ensures every interaction is engaging and intuitive. Ensure every educational session, whether in-person or remote, is seamless with the Avocor S Series. Its modern aesthetics and robust functionality make it the perfect solution for schools and universities seeking high performance, interactive displays.
Its diverse connectivity options support seamless integration with various educational tools and devices. Preloaded with applications like Bytello Class, Note, Share, and Browse, the S Series transforms standard lessons into interactive experiences, keeping students engaged and informed. For environments requiring Google's ecosystem, the S Series can also be configured with the Avocor Google EDLA certified slot-in OPS Android PC, offering seamless integration with Google Classroom and other Google productivity tools, making it a versatile solution for modern educational challenges.
Description
Powerful processing performance
The Avocor AVS-6510E features an Amlogic T982 quad-core processor, enhanced by 8 GB of RAM, ensuring swift multitasking and smooth operation for various applications.
Extensive connectivity options
This display includes multiple input types, such as HDMI, VGA, USB, and LAN, providing compatibility with a wide range of devices for diverse configurations.
Robust audio system
Equipped with built-in speakers that deliver a nominal output power of 16 watts, the AVS-6510E ensures clear sound without the need for additional external speakers.
Secure operational environment
Operating within a temperature range of 0°C to 40°C and with a humidity range of 10 - 90%, this display is built to perform reliably in various commercial settings.
User-friendly features
With features like Auto Source Mode and a remote control, the AVS-6510E provides an intuitive user experience, making it easy to switch between different inputs and control settings remotely.
Environmental Parameters | |
---|---|
Min Operating Temperature | 0 °C |
Max Operating Temperature | 40 °C |
Humidity Range Operating | 10 - 90% (non-condensing) |
Power | |
Power Device | Power supply |
Power Consumption Stand by | 0.5 Watt |
Input Voltage | AC 100-240 V (50/60 Hz) |
Media Player | |
USB Ports Qty | 3 |
USB Port | Yes |
Configuration | Amlogic T982 Quad-Core - 8 GB - 64 GB - Mali-G52 MP2 |
Manufacturer Warranty | |
Service & Support | Limited warranty - 3 years |
Display | |
Coating | Anti-glare |
Touchpoints Qty | 40 |
Image Aspect Ratio | 16:9 |
Viewing Angle | 178 degrees |
Viewing Angle (Vertical) | 178 degrees |
Image Contrast Ratio | 5000:1 |
Response Time | 6.5 ms |
Resolution | 3840 x 2160 |
LCD Backlight Technology | Direct-lit LED |
Display Format | 4K UHD (2160p) |
Brightness | 350 cd/m² |
Frame Rate & Enhancement Technology | 60 Hz Frequency |
Operation Hours / Days | 16 / 7 |
Colour Support | 1070000000 colours |
Commercial Features | OPS Slot, Auto Source Mode |
Features | 10-bit support, carrying handles, ARC Support through HDMI, CEC Support, customisable home screen, Device Management Solution (DMS), screen mirroring |
Dimensions & Weight (Shipping) | |
Depth (Shipping) | 20.8 cm |
Height (Shipping) | 100.5 cm |
Width (Shipping) | 162.8 cm |
Audio System | |
Output Power / Total | 32 Watt |
Speaker System | 2 speakers |
Speakers | 2 x main channel speaker - 16 Watt |
Remote Control | |
Battery Included | Yes |
Type | Remote control |
Stands & Mounts | |
Wall Mount Included | Yes |
VESA Compatibility | Yes |
Flat Panel Mount Interface | 600 x 400 mm |
General | |
Power Consumption (Max) | 360 Watt |
TV Tuner Presence | No |
HDMI Ports Qty | 3 ports |
Diagonal Class | 65" |
PC Interface | VGA (HD-15) |
Video Interface | HDMI |
Platform | Android |
Depth | 8.72 cm |
Series | S Series |
Product Type | LED-backlit LCD flat panel display |
Modes | Landscape mode |
Height | 89.66 cm |
Combined With | Touchscreen (multi touch) |
Design | Thin Bezel Design |
Width | 148.84 cm |
Commercial Use | Yes - interactive |
Protection | Bonded glass |
Operating System | Android OS 13 |
Network & Internet Multimedia | |
Connectivity | LAN, Wi-Fi |
Miscellaneous | |
Included Accessories | 2 fine-tip passive touch styluses, power cord |
Cables Included | USB 3.0 Type B to Type A cableHDMI cable |
Compliant Standards | HDCP 2.1, Google EDLA |
Connections | |
Connector Type | 2 x touchTouch2 x HDMI input - sideHDMI output - sideVGA input - side2 x USB 3.0 - sideUSB 2.0 - sideUSB-C with 65W Power Delivery - frontHDMI input - frontUSB 2.0 - frontAudio line-inAudio line-outSPDIF outputRS-2322 x LAN |
