Tripp Lite DWM3770X TV mount

Eaton Tripp Lite Series Display TV Wall Monitor Mount Swivel/Tilt 37" to 70" TVs / EA / Flat-Screens - Bracket - for flat panel - steel - black - screen size: 37"-70" - wall-mountable


Brand
TRIPP LITE
Product code
DWM3770X
SKU
O35E3DF0G9L4D
EAN/GTIN
037332187437
  • Fits most flat-panel displays from 37 to 70 in.
  • One-touch adjustment for comfortable viewing
  • 120° swivel, -15° to +15° tilt and -3° to +3° screen adjustment
  • Supports up to 165 lbs (74.8 kgs)
€179.01 (Inc. VAT)
Sold Out
(Delivery 2-4 working days)

Product Info

The VESA-compliant DWM3770X Swivel/Tilt Wall Mount allows you to mount your flat-panel television, monitor or other display on the wall. Ideal for home theaters, classrooms, boardrooms, hotels, bars and restaurants, it fits most flat-panel displays from 37 to 70 inches.

The articulating arm has six pivots that adjust independently for angle to give you maximum flexibility in positioning your display to fit your environment and comfort level. A 120° swivel, -15° to +15° tilt and -3° to +3° screen level adjustment capability minimizes glare and provides comfortable viewing from multiple angles.

Durable all-metal frame with scratch-resistant powder-coated finish supports up to 165 lbs (74.8 kgs). Mounting hardware included. Built-in bubble level allows accurate display leveling. Conforms to VESA-compliant displays with any of the following mounting hole patterns: 100 x 100 mm, 100 x 200 mm, 200 x 100 mm, 200 x 200 mm, 200 x 300 mm, 200 x 400 mm, 300 x 200 mm, 300 x 300 mm, 300 x 400 mm, 400 x 200 mm, 400 x 300 mm, 400 x 400 mm, 500 x 200 mm, 500 x 300 mm, 500 x 400 mm, 600 x 300 mm and 600 x 400 mm

Mounting
Minimum screen size 94 cm (37")
Maximum weight capacity 75 kg
Maximum screen size 177.8 cm (70")
Minimum VESA mount 100 x 100 mm
Maximum VESA mount 600 x 400 mm
Panel mounting interface 100 x 100,100 x 200,200 x 100,200 x 200,200 x 300,200 x 400,300 x 200,300 x 400,300 x 300,400 x 200,400 x 400,400 x 300,500 x 200,500 x 300,500 x 400,600 x 300,600 x 400
Number of displays supported 1
Mounting type Wall
Ergonomics
Height adjustment Yes
Tilt angle range -15 - 15°
Swivel angle 120°
Swivel angle range -3 - 3°
Design
Product colour Black
Technical details
Country of origin China
Packaging content
Manual Yes
Mounting kit Yes
Weight & dimensions
Width 601 mm
Depth 524 mm
Height 440 mm
Weight 7.88 kg
Packaging data
Package width 241.3 mm
Package depth 708.7 mm
Package height 111.8 mm
Package weight 9.34 kg
Logistics data
Master (outer) case width 251.5 mm
Master (outer) case length 718.8 mm
Master (outer) case height 254 mm
Master (outer) case gross weight 19.1 kg
Products per master (outer) case 2 pc(s)
Master (outer) case GTIN (EAN/UPC) 10037332187434
Harmonized System (HS) code 85299097
We do not guarantee the completeness and accuracy of the product details, which are obtained from outside sources.
