HPE ProLiant DL380 Gen11 Network Choice - Server - rack-mountable - 2U - 2-way - 1 x Xeon Gold 5416S / up to 4 GHz - RAM 32 GB - SATA/SAS/PCI Express - hot-swap 2.5" bay(s) - no HDD - Gigabit Ethernet, 10 Gigabit Ethernet - no OS - monitor: none - BTO
- Brand
- Hewlett Packard Enterprise
- Product code
- P52561-421
- SKU
- QRT98OWP4EPD7
- EAN/GTIN
- 190017648279
- Server
- rack-mountable 2U
- 2-way
- 1 x Xeon Gold 5416S / up to 4 GHz
- RAM 32 GB
- SATA/SAS/PCI Express
- hot-swap 2.5" bay(s)
- no HDD
- Gigabit Ethernet, 10 Gigabit Ethernet
- no OS
- monitor: none
- BTO
- Weight: 25.18 KG
Product Info
Adaptable for diverse workloads and environments, the secure 2P 2U HPE ProLiant DL380 Gen11 delivers world-class performance with the right balance of expandability and scalability. Designed for supreme versatility and resiliency make it ideal for multiple environments from Containers to Cloud to Big Data.
Description
Energy-efficient design
With ENERGY STAR certification, the HPE ProLiant DL380 Gen11 Network Choice server ensures eco-friendly operation, reducing your data center's carbon footprint and operational costs.
Advanced memory technology
Equipped with HPE SmartMemory and 32 DIMM slots supporting DDR5 SDRAM, this server offers enhanced data transfer rates and energy efficiency, providing a robust foundation for memory-intensive applications.
Flexible expansion options
Featuring a variety of expansion slots including FlexibleLOM and PCIe x16, the server offers ample room for growth and customization, allowing for tailored configurations that meet specific workload demands.
Robust remote management
Integrated Lights-Out technology facilitates comprehensive remote management capabilities, enabling efficient server monitoring, maintenance, and issue resolution, minimizing downtime.
Versatile networking and connectivity
With support for PXE and Wake on LAN (WoL), alongside dedicated RJ-45, HPE iLO, and VGA interfaces, this server ensures versatile connectivity options for diverse networking environments.
| Monitor | |
|---|---|
| Monitor Type | None. |
| Processor / Chipset | |
| CPU Qty | 1 |
| Max CPU Qty | 2 |
| CPU Upgradability | Upgradable |
| Clock Speed | 2 GHz |
| Max Turbo Speed | 4 GHz |
| Processor Main Features | Intel Turbo Boost Technology |
| Number of Cores | 16-core |
| Chipset Type | Intel C741 |
| CPU | Intel Xeon Gold 5416S |
| Power | |
| Installed Qty | 1 |
| Max Supported Qty | 2 |
| Power Redundancy | Optional |
| Device Type | Power supply - hot-plug |
| Voltage Required | AC 100/240 V |
| Power Provided | 1000 Watt |
| Power Redundancy Scheme | 1+1 (with optional power supply) |
| 80 PLUS Certification | 80 PLUS Titanium |
| General | |
| Type | Server |
| Hot-Swap Bays Qty | 8 |
| Built-in Devices | Led panel |
| Server Scalability | 2-way |
| Product Form Factor | Rack-mountable - 2U |
| Localisation | Region: European Union |
| Environmental Parameters | |
| Min Operating Temperature | 10 °C |
| Max Operating Temperature | 35 °C |
| Humidity Range Operating | 8 - 90% RH (non-condensing) |
| Dimensions & Weight | |
| Width | 44.8 cm |
| Weight | 16 kg |
| Height | 8.75 cm |
| Depth | 72.7 cm |
| Graphics Controller | |
| Video Memory | 16 MB |
| Video Interfaces | VGA |
| Storage Controller | |
| Channel Qty | 8 |
| Buffer Size | 4 GB |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
| Controller Interface Type | SATA 6Gb/s / SAS 12Gb/s / PCIe |
| Type | 1 x RAID - PCIe 4.0 x8 |
| Storage Controller Name | HPE Smart Array MR408i-o |
| Sustainability Information | |
| ENERGY STAR Version | 3.0 |
| ENERGY STAR Certified | Yes |
| Cache Memory | |
| Cache Per Processor | 30 MB |
| Installed Size | L3 Cache - 30 MB |
| Miscellaneous | |
| Pricing Type | BTO |
| Compliant Standards | AES, TLS v1.2, ACPI 6.3, ASHRAE Class A3, ASHRAE Class A4, ErP Lot 9, WEEE 2002/95/EC, FIPS 140-2 |
| Included Accessories | 4 standard fans, HPE Easy Install Rails, cable management arm |
| Networking | |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet |
| Features | Wake on LAN (WoL), PXE support |
| Ethernet Ports | 2 x 10 Gigabit Ethernet |
| Remote Management Protocol | SNMP 3, IPMI 2.0, SMASH CLP |
| Ethernet Controller | Broadcom BCM57416 |
| Compliant Standards | OCP 3.0 |
| Remote Management Controller | Integrated Lights-Out 6 |
| RAM | |
| Configuration Features | 1 x 32 GB |
| Form Factor | DIMM 288-pin |
| Rated Memory Speed | 4800 MHz |
| Slots | 32 (Total) / 31 (empty) |
| Effective Memory Speed | 4400 MHz |
| Technology | DDR5 SDRAM |
| Installed Size | 32 GB (installed) / 8 TB (max) |
| Features | HPE SmartMemory, registered, slots 17 - 32 are available in two-processor configuration only |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labour - 3 years - on-site - response time: next business day |
| Operating System / Software | |
| OS Provided | No operating system |
| Software | HPE Server UEFI |
| OS Certified | Microsoft Windows Server, VMware ESXi, Red Hat Enterprise Linux, Canonical Ubuntu, Oracle Linux, Citrix |
| Hard Drive | |
| Type | No HDD |
| Optical Storage | |
| Type | No optical drive |
| Expansion / Connectivity | |
| Bays | 1 (total) / 1 (free) x external Universal Media Bay8 (total) / 8 (free) x hot-swap 2.5" SFF |
| Slots | 2 (total) / 2 (free) x FlexibleLOM1 (total) / 1 (free) x PCIe 5.0 x16 - full-length, full-height1 (total) / 1 (free) x PCIe 5.0 x16 - full-length, full-height (x8 mode)1 (total) / 1 (free) x PCIe 5.0 x16 - half-length, full-height (x8 mode) |
| Interfaces | 1 x USB 3.0 (1 in front) (HPE iLO Service Port)4 x USB 3.0 (2 rear, 2 internal)1 x HPE iLO - RJ-45 (1 rear)1 x VGA (1 rear)2 x LAN (10Gigabit Ethernet) - RJ-45 |
