HPE ProLiant DL20 Gen11 High Performance - Server - rack-mountable - 1U - 1-way - 1 x Xeon E-2436 / up to 5 GHz - RAM 16 GB - SATA - hot-swap 2.5" bay(s) - no HDD - Matrox G200 - Gigabit Ethernet - no OS - monitor: none
- Brand
- Hewlett Packard Enterprise
- Product code
- P65396-421
- SKU
- VDL4ZIXXDIIVG
- EAN/GTIN
- 190017686950
- Server
- rack-mountable 1U
- 1-way
- 1 x Xeon E-2436 / up to 5 GHz
- RAM 16 GB
- SATA
- hot-swap 2.5" bay(s)
- no HDD
- Matrox G200
- Gigabit Ethernet
- no OS
- monitor: none
- Weight: 12.64 KG
Product Info
Are you looking for a compact and versatile 1U server that supports edge workloads like security monitoring in a variety of environments? The reliable HPE ProLiant DL20 Gen11 server delivers a compact and versatile server with enhanced security at an affordable price. Deploy the short-depth rack form factor in small, remote, or branch offices, as a powerful point of sale platform in transport, retail, and hospitality environments or as a flexible configuration for customization in space constrained environments of military and government customers. Blending performance, reliability, and manageability, this one-socket, 1U server featuring Intel Xeon E processors provide unique enterprise-class capabilities at a great value - making it an ideal rack server platform for growing businesses, enterprises, and service providers. Outstanding configuration flexibility caters to a variety of business requirements and a wide range of qualified options fits a variety of needs.
Description
Compact, secure, and reliable design for an affordable solution
HPE ProLiant DL20 Gen11 server is a short-depth chassis of 15. 05 inches, providing mobility and easy deployment in a wide variety of environments. HPE ProLiant DL20 Gen11 server has great quality and design features that are a hallmark of the HPE ProLiant family such as tool-less access to system components and enhanced serviceability. Handle a range of light workloads to more demanding requirements with affordable configuration choices and a wide variety of Hewlett Packard Enterprise qualified options.
Right balance of performance, flexibility, reliability, and manageability for growing business needs
HPE ProLiant DL20 Gen11 server offers a wide choice of dual-core, quad-core, hexa-core or octa-core Intel Xeon E processors with up to 128 GB of DDR5 ECC memory to handle your workload demands. Experience outstanding configuration flexibility with support for up to two large form factor (LFF) or six small form factor (SFF) drives, four DDR5 ECC UDIMMs, 290W, 500W, 800W or 1000W power supplies, and a more efficient deployment of options via HPE PCIe and OCP slots - now supporting PCIe 5. 0. The reliable HPE ProLiant DL20 Gen11 server combines a dense and compact form factor with redundant power supply capability, which keeps your business running and provides data protection and accessibility even in the event of a power supply failure.
Security innovations
Only Hewlett Packard Enterprise offers industry-standard servers, such as the HPE ProLiant DL20 Gen11server, with major firmware anchored directly into the silicon and with security protection built in across the server life-cycle, starting with Silicon Root of Trust from HPE. Millions of lines of firmware code run before the server operating system boots. With Runtime Firmware Verification, enabled by the optional HPE iLO Advanced Premium Security Edition, the server's firmware is checked every 24 hours, verifying validity and credibility of essential system firmware. Secure Recovery allows server firmware to roll back to the last known good state or factory settings after detection of compromised server.
Services and ease of deployment
HPE ProLiant DL20 Gen11 server comes standard with a complete set of services from HPE Services, delivering confidence, reducing risk, and helping customers realize agility and stability. HPE Services simplify the stages of your IT journey. Advisory and Transformation Services professionals understand customer challenges and design an ideal solution. Professional Services enables rapid deployment of solutions. Operational Services from HPE Services includes: HPE Complete Care, HPE Tech Care and project-based services, such as Integration and Performance services. Additional services can be added to customize your experience at any stage of your IT lifecycle. HPE IT investment solutions help you transform to a digital business with IT economics that align to your business goals.
| Monitor | |
|---|---|
| Monitor Type | None. |
| Processor / Chipset | |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| CPU Upgradability | Upgradable |
| Max Turbo Speed | 5 GHz |
| Clock Speed | 2.9 GHz |
| Number of Cores | 6-core |
| Processor Main Features | Intel Turbo Boost Technology 2, Intel Smart Cache |
| CPU | Intel Xeon E-2436 |
| Chipset Type | Intel C262 |
| Power | |
| Installed Qty | 1 |
| Max Supported Qty | 2 |
| Power Redundancy | Optional |
| Device Type | Power supply - hot-plug |
| Power Provided | 800 Watt |
| Voltage Required | AC 100-120/200-240 V |
| Power Redundancy Scheme | 1+1 (with optional power supply) |
| 80 PLUS Certification | 80 PLUS Platinum |
| General | |
| Type | Server |
| Built-in Devices | Led panel |
| Hot-Swap Bays Qty | 4 |
| Server Scalability | 1-way |
| Product Form Factor | Rack-mountable - 1U |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Localisation | Region: EMEA |
| Environmental Parameters | |
| Min Operating Temperature | 10 °C |
| Max Operating Temperature | 35 °C |
| Sound Emission | 27 dBA |
| Humidity Range Operating | 8 - 90% RH (non-condensing) |
| Graphics Controller | |
| Video Memory | 16 MB |
| Graphics Processor | Matrox G200 |
| Video Interfaces | DisplayPort, VGA |
| Sustainability Information | |
| ENERGY STAR Version | 4.0 |
| ENERGY STAR Certified | Yes |
| Dimensions & Weight | |
| Weight | 9 kg |
| Height | 4.32 cm |
| Width | 43.46 cm |
| Depth | 37.84 cm |
| Networking | |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Ethernet Ports | 4 x Gigabit Ethernet |
| Ethernet Controller | Broadcom BCM5719 |
| Features | ACPI support, PXE support, Wake on LAN (WoL) |
| Remote Management Protocol | IPMI 2.0, SNMP 3 |
| Cache Memory | |
| Cache Per Processor | 18 MB |
| Installed Size | L3 Cache - 18 MB |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labour - 3 years - on-site - response time: next business day |
| Storage Controller | |
| Type | SATA |
| Controller Interface Type | SATA 6Gb/s |
| Storage Controller Name | Intel VROC SATA Software RAID |
| RAID Level | RAID 1, RAID 0, RAID 5, RAID 10 |
| RAM | |
| Configuration Features | 1 x 16 GB |
| Installed Size | 16 GB (installed) / 128 GB (max) |
| Form Factor | DIMM 288-pin |
| Effective Memory Speed | 4800 MHz |
| Rated Memory Speed | 4800 MHz |
| Slots | 4 (Total) / 3 (empty) |
| Technology | DDR5 SDRAM - ECC |
| Features | HPE Standard Memory, unbuffered |
| Operating System / Software | |
| OS Provided | No operating system |
| OS Certified | Microsoft Windows Server 2019, Microsoft Windows Server 2022, VMware ESXi 8.0 update 2 |
| Software | HPE iLO Management, HPE Intelligent Provisioning |
| Hard Drive | |
| Type | No HDD |
| Optical Storage | |
| Type | No optical drive |
| Expansion / Connectivity | |
| Bays | 4 (total) / 4 (free) x hot-swap 2.5" SFF1 (total) / 1 (free) x external |
| Slots | 1 (total) / 1 (free) x PCIe 5.0 x16 - half-length, full-height (x16 mode)1 (total) / 1 (free) x Open Compute Project mezzanine (OCP) 3.0 |
| Interfaces | 1 x HPE iLO - Type A (1 in front) (service port)5 x USB 3.2 Gen 1x1 - Type A (1 front, 4 rear)2 x USB 3.2 Gen 2x2 (2 internal)1 x DisplayPort1 x VGA4 x LAN (Gigabit Ethernet) - RJ-45 |
| Miscellaneous | |
| Included Accessories | 3 performance single rotor non-hot plug and non-redundant fans, HPE Short Friction Rail kit |
| Compliant Standards | AES, Triple DES, ACPI 6.3, SMBIOS 3.2, Redfish API, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, Active Directory v1.0, UEFI 2.9, PCI DSS, FIPS 140-2, IPv6 Ready, WEEE 2002/95/EC, EU Lot 9 |
