Sony BRC-X400 - Conference camera - PTZ - colour - 3840 x 2160 - 1080/59.94p, 2160/29.97p - 1700 TVL - audio - HDMI, 3G-SDI - DC 12 V / PoE Plus
- Brand
- Sony
- Product code
- BRC-X400/W
- SKU
- 591H2A555JZ94
- EAN/GTIN
- 4548736104747
- Conference camera
- PTZ
- colour
- 3840 x 2160
- 2160/29.97p, 1080/59.94p
- 1700 TVL
- audio
- HDMI, 3G-SDI
- DC 12 V / PoE Plus
- Weight: 3.70 KG
Product Info
The versatile BRC-X400 PTZ camera is ideal for use in a wide range of environments - from broadcast studios and remote on-air suites to sports stadiums, arenas, houses of worship and lecture halls.
The camera's 1/2.5-type Exmor R CMOS sensor captures broadcast quality 4K images with excellent sensitivity, very low noise and rich, natural color reproduction.
Installation and set-up is easy, with a Scene File function allowing the same settings to be applied to multiple cameras. Convenient integration in multi-camera live events is also simplified with genlock support and an 'on-air' tally lamp.
Description
Excellent 4K images, even in low light
The sensitive 1/2. 5-type Exmor R sensor captures high-quality 4K images with very low noise, even in dimly-lit environments.
Up to 80x zoom
Powerful zoom up to 80x allows frame-filling close-ups with fine details seen clearly. Responsive autofocus ensures that images stay clear and sharp, even at high zoom settings.
Wide viewing angle
Cover the whole scene in sports arenas and lecture theaters with a horizontal viewing angle of approx. 70 degrees.
Remote viewing
View pictures remotely over the Internet from a web browser, with support for RTSP (Real Time Streaming Protocol) and RTMP (Real Time Messaging Protocol).
Simpler installation, lower costs
A single IP cable carries camera power, video image output and control signals to simplify installation and reduce cabling costs.
Ideal for live production
Genlock allows seamless multi-camera switching in live events. The camera's inbuilt tally lamp is ideal for live productions and reality shows.
| Miscellaneous | |
|---|---|
| Colour | White |
| Compliant Standards | IEEE 802.3at |
| Camera | |
| Digital Zoom | 12 |
| Frame Rate (max) | 30 frames per second |
| Horizontal Resolution (TV Lines) | 1700 |
| Type | Colour - pan / tilt / zoom |
| Max Digital Video Resolution | 3840 x 2160 |
| Features | 256 preset positions |
| Minimum Illumination | 1.6 lux F2.0 - 50 IRE - shutter 1/30 sec |
| Video Modes | 2160/29.97p, 1080/59.94p |
| General | |
| Camera Mount Type | Ceiling mount |
| Connectivity Technology | Wired |
| Audio Support | Yes: two-way audio capability |
| Device Type | Conference camera |
| Panning | |
| Speed (degree/sec) | Up to 300 |
| Range (degree) | -170 to +170 |
| Tilting | |
| Range (degree) | -20 to +90 |
| Speed (degree/sec) | Up to 126 |
| Power | |
| Power Requirements | DC 12 V / PoE Plus |
| Interfaces | |
| Video | HDMI, 3G-SDI |
| Control Interface | VISCA |
| Image Sensor | |
| Type | Exmor R CMOS 1/2.5" |
| Expansion / Connectivity | |
| Ports | 2 x serial RS-422 - RJ-453G-SDIHDMI outputLAN/power - RJ-45 |
