Sony BRC-H800 - Conference camera - PTZ - colour (Day&Night) - 20.4 MP - motorized - 850 TVL - HDMI, 3G-SDI - DC 10.8 - 13.2 V / PoE Plus
- Brand
- Sony
- Product code
- BRC-H800/AC
- SKU
- IJUEN94TN84ZS
- EAN/GTIN
- 5054444000251
- Conference camera
- PTZ
- colour (Day&Night)
- 20.4 MP
- motorized
- 850 TVL
- HDMI, 3G-SDI
- DC 10.8
- 13.2 V / PoE Plus
- Weight: 8.68 KG
Product Info
The BRC-H800 remote camera combines uncompromising broadcast picture quality and smooth, silent PTZ operation with the flexibility of 3G-SDI and HDMI connections. Designed for unattended operation, this compact but powerful robotic camera is an ideal complement to other broadcast cameras for capturing images in hard-to-reach or unobtrusive positions. It's equally at home in TV newsrooms, remote studios and on-air suites, auditoriums, houses of worship, courtrooms or sports stadiums. It's also particularly suited to efficient multi-camera set-ups, under the control of a single operator.
Description
Enhanced pan/tilt/zoom operation
Accurately re-frame shots or track moving subjects with smooth, speedy, near-silent remote control of pan, tilt and zoom functions. There's also low-speed zoom and a slow pan/tilt mode for precise, judder-free camera movements.
Excellent low light sensitivity
The BRC-H800 can capture crisp, low noise color video images in low light levels, making it an ideal choice for dimly lit live hall and theater.
Flexible installation
Integration is simplified in a wide range of environments, with PoE+ to reduce cabling requirements and VISCA control over IP.
Front and rear tally lamps
Ideal for on-air broadcast use, the BRC-H800 features dual tally lamps on the front and rear of the camera body. Brightness of the front tally lamp can be adjusted in two steps.
| Environmental Parameters | |
|---|---|
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Miscellaneous | |
| Colour | Black |
| Included Accessories | Remote control, wire rope, 2 ceiling mount brackets |
| General | |
| Height | 26 cm |
| Weight | 4.3 kg |
| Depth | 23.8 cm |
| Width | 19.8 cm |
| Camera Mount Type | Ceiling mount |
| Connectivity Technology | Wired |
| Device Type | Conference camera |
| Lens Construction | |
| Min Focus Distance | 8 cm |
| Focus Adjustment | Automatic, manual |
| Optical Zoom | 12 x |
| Lens Iris | F/2.8-4.5 |
| Type | Motorized zoom |
| Horizontal Field of View (degree) | 64.6 |
| Focal Length | 9.3 mm - 111.6 mm |
| Camera | |
| Horizontal Resolution (TV Lines) | 850 |
| Frame Rate (max) | 60 frames per second |
| Type | Colour - Day&Night - pan / tilt / zoom |
| Video Modes | 1080/50i, 720/50p, 1080/50p, 1080/60p, 1080/59.94i, 1080/59.94p, 720/59.94p |
| Exposure Range | 1/6 sec - 1/10000 sec |
| Minimum Illumination | 1.7 lux F2.8 - 50 IRE - shutter 1/30 sec |
| Features | Auto exposure control, image flip, Visibility Enhancer, Clear Image Zoom, 16 preset positions, back illuminated sensor, auto gain control, auto white balance |
| Panning | |
| Range (degree) | -170 to +170 |
| Speed (degree/sec) | Up to 60 |
| Tilting | |
| Range (degree) | -30 to +90 |
| Speed (degree/sec) | Up to 60 |
| Interfaces | |
| Video | HDMI, 3G-SDI |
| Control Interface | RS-422, VISCA |
| Image Sensor | |
| Type | 20.4 MP Exmor R CMOS 1" |
| Expansion / Connectivity | |
| Ports | 2 x 3G-SDIHDMILAN - RJ-45 |
| Power | |
| Power Requirements | DC 10.8 - 13.2 V / PoE Plus |
| Power Device | Power adapter 23 Watt |
