K/AVL-1050-T+Rally Bar
- Brand
- AVOCOR
- Product code
- AVO-AVL-1050T-RB
- SKU
- Y7GYK2D973CUO
Product Info
Beautiful, brushed aluminum industrial design, ideal for large rooms used for interactive meetings and training.
The unique 21:9 aspect ratio provides increased width for a more usable interactive area. A smooth, highly responsive projected-capacitive touch features high durability, excellent optical performance and multi-touch with a fine-tip stylus or finger along with palm rejection. The split-screen ability to have both a presentation and a whiteboard on-screen simultaneously will bring a new level of productivity and audience engagement, supporting collaboration before, during, and after meetings.
Description
Innovative audio system
Equipped with a dynamic speaker system that includes two main channel speakers and a powerful subwoofer, delivering a total nominal RMS output power of 31 watts. This setup ensures clear, immersive audio for any interactive communication.
Versatile connectivity
Features a comprehensive range of connector types including HDMI, DisplayPort, USB-C with 100 W Power Delivery, and more, located conveniently on the side for easy access. This allows for seamless integration with a variety of devices.
Advanced environmental adaptability
Designed to operate within a wide range of humidity (10 - 90%) and temperature (0°C to 40°C), ensuring reliable performance in diverse operating conditions.
High-definition display
Boasts a 105-inch LED-backlit LCD flat panel display with 5K UHD (2160p) resolution, anti-fingerprint and anti-glare coatings, and a 4000:1 image contrast ratio. The display offers a wide viewing angle of 178°, both horizontally and vertically, for superior visual clarity from any perspective.
Interactive features
Incorporates Avocor Intelligent Touch and Avocor UiQ technology, along with a touchscreen that supports up to 40 touchpoints. This, combined with an array of sensors including CO2/VOCS, presence, ambient light, color temperature, and humidity sensors, enhances user interaction and engagement.
| Environmental Parameters | |
|---|---|
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 10 - 90% |
| Power | |
| Power Device | Power supply |
| Power Consumption Stand by | 0.5 Watt |
| Input Voltage | AC 100-240 V (50/60 Hz) |
| Media Player | |
| USB Ports Qty | 6 |
| USB Port | Yes |
| Dimensions & Weight (Shipping) | |
| Depth (Shipping) | 42.5 cm |
| Weight (Shipping) | 138 kg |
| Height (Shipping) | 125.5 cm |
| Width (Shipping) | 270.3 cm |
| Display | |
| Touchpoints Qty | 40 |
| Image Contrast Ratio | 4000:1 |
| Viewing Angle | 178 degrees |
| Viewing Angle (Vertical) | 178 degrees |
| Response Time | 6.5 ms |
| Image Aspect Ratio | 21:9 |
| Coating | Anti-glare, anti-fingerprint |
| LCD Backlight Technology | Direct-lit LED |
| Resolution | 5120 x 2160 |
| Display Format | 5K UHD (2160p) |
| Brightness | 400 cd/m² |
| Frame Rate & Enhancement Technology | 60 Hz Frequency |
| Features | Avocor Intelligent Touch, optical bonding, OPS Slot, Avocor UiQ |
| General | |
| Power Consumption Operational | 600 Watt |
| HDMI Ports Qty | 4 ports |
| TV Tuner Presence | No |
| Weight | 99 kg |
| Video Interface | HDMI |
| Power Consumption (Max) | 665 Watt |
| PC Interface | DisplayPort |
| Product Type | LED-backlit LCD flat panel display |
| Series | L Series |
| Depth | 9.63 cm |
| Modes | Landscape mode |
| Diagonal Class | 105" |
| Combined With | Touchscreen (multi touch) |
| Commercial Use | Yes - interactive |
| Height | 112.33 cm |
| Width | 251.06 cm |
| Sensors | Presence sensor, ambient light sensor (ALS), colour temperature sensor, humidity sensor, CO2/VOCS sensor |
| Design | Ultra thin bezel, edge-to-edge design, Sleek Design |
| Stands & Mounts | |
| VESA Compatibility | Yes |
| Flat Panel Mount Interface | 1000 x 400 mm |
| Miscellaneous | |
| Included Accessories | Stylus |
| Cables Included | Power cable (C14)HDMI cableUSB-A to USB-B cable |
| Remote Control | |
| Type | Remote control |
| Audio System | |
| Speaker System | 2 speakers, subwoofer |
| Speakers | 2 x main channel speaker - 16 Watt1 x subwoofer - 15 Watt |
| Connections | |
| Connector Type | 4 x HDMI input - sideDisplayPort input - sideUSB-C with 100W Power Delivery - side3 x touch in - sideService - sideHDMI output - side2 x USB 3.0 - side2 x USB 3.0 - top2 x USB 2.0 - bottomSPDIF outputAudio line-outRemote control inputRS-2322 x LAN |
