Cisco Catalyst 9300L

C9300L-48UXG-2Q-E - 889728174114

Cisco Catalyst 9300L - Network Essentials - switch - L3 - Managed - 36 x 10/100/1000 (UPOE) + 2 x 40Gb Ethernet + 12 x 1/2.5/5/10GBase-T - rack-mountable - UPOE (675 W)

Brand: Cisco
Product code: C9300L-48UXG-2Q-E
SKU: 95M4ISUP9Z8P8
EAN/GTIN: 889728174114

€16393.34 (Inc. VAT)

Sold Out

(Delivery 2-4 working days)

Specifications

General

Device type Switch - 48 ports - L3 - Managed - stackable

Enclosure Type Rack-mountable

Subtype Gigabit Ethernet

Ports 36 x 10/100/1000 (UPOE) + 2 x 40Gb Ethernet + 12 x 1/2.5/5/10GBase-T

Power over Ethernet (PoE) UPOE

PoE Budget 675 W

Performance Switching capacity:472 Gbps Switching capacity with stacking:792 Gbps Forwarding rate:351.19 Mpps Forwarding rate with stacking:589.28 Mpps

Capacity IPv4 routes:32000 IPv6 routes:16000 Multicast scale:8000 QoS scale entries:5120 ACL scale entries:5120 VLANs supported:4094 Switched virtual interfaces (SVIs):1000 Packet buffer size:16 MB

MAC Address Table Size 32000 entries

Jumbo Frame Support 9198 bytes

Routing Protocol OSPF, RIP-1, RIP-2, EIGRP, VRRP, PIM-SM, EIGRP for IPv6, OSPFv3, PIM-SSM, policy-based routing (PBR), RIPng, MSTP

Remote Management Protocol SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF, gRPC, IPv4, IPv6, YANG

Encryption Algorithm 128-bit AES, 256-bit AES

Features Access Control List (ACL) support, Quality of Service (QoS), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Shaped Round Robin (SRR), PXE support, Energy Efficient Ethernet, Class of Service (CoS), Flexible NetFlow (FNF), 802.1x authentication, DiffServ Code Point (DSCP) support, MACsec support, Control plane protection (CoPP), Blue Beacon LED, Zero-touch provisioning (ZTP), secure boot, Protocol Independent Multicast (PIM), First Hop Security (FHS), PVLAN support, Committed Information Rate (CIR), Cisco Trust Anchor module, Cisco Unified Access Data Plane (UADP) 2.0, Cisco StackWise-320 technology

Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ae, IEEE 1588v2, IEEE 802.1BA, IEEE 802.3bt, Wi-Fi CERTIFIED 6

RAM 8 GB

Flash memory 16 GB

Status Indicators Status

Expansion / Connectivity

Interfaces 36 x 1000Base-T RJ-45 60 W 2 x 40Gbit LAN uplink 1 x network stack device 1 x management (LAN) RJ-45 1 x console 1 x USB 2.0 12 x 1/2.5/5/10GBase-T RJ-45

Power

Power Device Internal power supply - hot-plug

Installed Qty 1

Max Supported Qty 2

Power Redundancy Optional

Power Provided 1100 Watt

Voltage Required AC 120/230 V (50 - 60 Hz)

Miscellaneous

MTBF 275,010 hours

Compliant Standards CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN 61000-6-1, AS/NZS 60950-1, CCC, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Class A, VCCI Class A, CNS 13438, EN 55022 Class A, FCC CFR47 Part 15 B Class A, EN 300 386, KN32, KN35, EN 55032 Class A, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, TCVN 7189 Class A, V-3 Class A, TCVN 7317, CISPR 35

Dimensions & Weight

Width 44.5 cm

Depth 4.4 cm

Height 48.8 cm

Weight 7.65 kg

Manufacturer Warranty

Service & Support Limited warranty - replacement - lifetime - response time:next business day Technical support - consulting - 90 days

Environmental Parameters

Min Operating Temperature -5 °C

Max Operating Temperature 45 °C

Humidity Range Operating 5 - 90% (non-condensing)

Min Storage Temperature -40 °C

Max Storage Temperature 70 °C

Humidity Range Storage 5 - 90% (non-condensing)
