Intel Core i7-6820EQ processor

CL8066201939103 - 8592978120207

Intel Core i7 6820EQ - 2.8 GHz - 4 cores - 8 threads - 8 MB cache - LGA1440 Socket - OEM

Brand: Intel
Product Family: Core
Product series: i7
Product code: CL8066201939103
SKU: TFI01PUWB83Y8
EAN/GTIN: 8592978120207

Intel® Core™ i7 i7-6820EQ 2.8 GHz
8 MB Smart Cache BGA 1440
Processor cores: 4 14 nm 64-bit 45 W
Maximum internal memory supported by processor: 64 GB DDR4-SDRAM, LPDDR3-SDRAM, DDR3L-SDRAM
On-board graphics card Intel® HD Graphics 530

€459.77 (Inc. VAT)

Sold Out

(Delivery 2-4 working days)

Product Info

The 6th generation Intel® Core™ i7 processors deliver a new class of computing with a host of new features to power the next generation of laptops and 2 in 1 PCs. Expect lighting fast speeds and peak performance through even the toughest of tasks and games. The built-in revolutionary Intel® Hyper-Threading Technology allows each processor core to work on two tasks at the same time for smoother multitasking while Intel® Iris™ graphics delivers stunning 3D visuals and faster, more advanced video and photo editing. Game the way you want and push the boundaries with overclocking for your most demanding gaming needs. The ultimate in peak performance.

Ready. Wake. Create
From zero to power in a flash, the 6th generation Intel® Core™ processor wakes quicker than ever and lets you switch in and out of apps more seamlessly than ever.

Stunning Visual Experiences
With 6th generation Intel® Core™ processor Ultra HD graphics, your screen comes to life. Watch in a whole new way with 4k screens. Wireless displays let you create and game anywhere.

Security You Can Trust
Worry-free and hassle-free security is yours. With facial recognition and True Key™ technology, getting you logged in and protected has never been easier or more secure.

Specifications

Processor

Processor manufacturer Intel

Processor generation 6th gen Intel® Core™ i7

Processor model i7-6820EQ

Processor base frequency 2.8 GHz

Processor family Intel® Core™ i7

Processor cores 4

Processor socket BGA 1440

Component for Laptop

Processor lithography 14 nm

Processor series Intel Core i7-6800 Mobile Series

Processor threads 8

System bus rate 8 GT/s

Processor operating modes 64-bit

Processor boost frequency 3.5 GHz

Processor cache 8 MB

Processor cache type Smart Cache

Thermal Design Power (TDP) 45 W

Box No

Cooler included No

Generation 6th Generation

Stepping R0

Bus type DMI3

Memory bandwidth supported by processor (max) 34.1 GB/s

Processor codename Skylake

Processor code SR2DT

Processor ARK ID 90426

Memory

Maximum internal memory supported by processor 64 GB

Memory types supported by processor DDR4-SDRAM, LPDDR3-SDRAM, DDR3L-SDRAM

Memory clock speeds supported by processor 1600,1866,2133 MHz

Memory channels Dual-channel

ECC No

Graphics

On-board graphics card Yes

On-board graphics card model Intel® HD Graphics 530

Maximum on-board graphics card memory 64 GB

On-board graphics card outputs supported Embedded DisplayPort (eDP), DisplayPort, HDMI, DVI

On-board graphics card base frequency 350 MHz

On-board graphics card dynamic frequency (max) 1000 MHz

Number of displays supported (on-board graphics) 3

On-board graphics card 4K support Yes

On-board graphics card DirectX version 12.0

On-board graphics card OpenGL version 4.5

On-board graphics card maximum resolution (DisplayPort) 4096 x 2304 pixels

On-board graphics card maximum resolution (eDP - Integrated Flat Panel) 4096 x 2304 pixels

On-board graphics card maximum resolution (HDMI) 4096 x 2304 pixels

On-board graphics card refresh rate at maximum resolution (DisplayPort) 60 Hz

On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) 60 Hz

On-board graphics card refresh rate at maximum resolution (HDMI) 24 Hz

On-board graphics card ID 0x191B

Features

Execute Disable Bit Yes

Idle States Yes

Thermal Monitoring Technologies Yes

Market segment Embedded

Maximum number of PCI Express lanes 16

PCI Express slots version 3.0

PCI Express configurations 1x16, 2x8, 1x8+2x4

Supported instruction sets SSE4.1, SSE4.2, AVX 2.0

CPU configuration (max) 1

Embedded options available Yes

Graphics & IMC lithography 14 nm

PCI Express CEM revision 3.0

Export Control Classification Number (ECCN) 5A992C

Commodity Classification Automated Tracking System (CCATS) G077159

Processor special features

Intel® Hyper Threading Technology (Intel® HT Technology) Yes

Intel® Identity Protection Technology (Intel® IPT) Yes

Intel® Turbo Boost Technology 2.0

Intel® Quick Sync Video Technology Yes

Intel® InTru™ 3D Technology Yes

Intel® Wireless Display (Intel® WiDi) Yes

Intel® Clear Video HD Technology (Intel® CVT HD) Yes

Intel® Insider™ Yes

Intel® AES New Instructions (Intel® AES-NI) Yes

Enhanced Intel SpeedStep Technology Yes

Intel Trusted Execution Technology Yes

Intel® Memory Protection Extensions (Intel® MPX) Yes

Intel® Turbo Boost Technology 2.0 frequency 3.5 GHz

Intel® Transactional Synchronization Extensions Yes

Intel Enhanced Halt State Yes

Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) Yes

Intel VT-x with Extended Page Tables (EPT) Yes

Intel® Secure Key Yes

Intel TSX-NI Yes

Intel® OS Guard Yes

Intel Clear Video Technology Yes

Intel Software Guard Extensions (Intel SGX) Yes

Intel 64 Yes

Intel Identity Protection Technology version 1.00

Intel Secure Key Technology version 1.00

Intel Virtualization Technology (VT-x) Yes

Intel Virtualization Technology for Directed I/O (VT-d) Yes

Intel TSX-NI version 1.00

Conflict-Free processor Yes

Intel® Boot Guard Yes

Intel® vPro™ Platform Eligibility Yes

Operational conditions

Tjunction 100 °C

Technical details

Bus bandwidth 8

Bus type units GT/s

Launch date Q4'15

Maximum resolution & refresh rate (DisplayPort) 4096x2304@60Hz

Maximum resolution & refresh rate (HDMI) 4096x2304@24Hz

Maximum resolution & refresh rate (Integrated Flat Panel) 4096x2304@60Hz

Maximum resolution & refresh rate (VGA) N/A

Processor cache 8192 KB

Product type Processor

Status Launched

Maximum memory 64 GB

Processor brand name Intel Core i7 Intel Core i7 Processor

Supported memory types DDR4-SDRAM, LPDDR3-SDRAM, DDR3L-SDRAM

Last change 63903513

Maximum resolution (WiDi) 1080p

Product family 6th Generation Intel Core i7 Processors

Bus speed 8 GT/s

Maximum graphics card memory 64 GB

Processor ID 0x191B

Servicing status End of Servicing Lifetime

End of servicing updates date Friday, September 30, 2022

Logistics data

Harmonized System (HS) code 8542310001

Weight & dimensions

Processor package size 42mm x 28mm

Other features

Maximum internal memory 64 GB

Maximum internal memory 65536 MB

Graphics output eDP/DP/HDMI/DVI

Video decoding Yes
