Intel Core i3-7100E processor
Intel Core i3 7100E - 2.9 GHz - 2 cores - 4 threads - 3 MB cache - FCBGA1440 Socket - OEM
- Brand
- Intel
- Product Family
- Core
- Product series
- i3
- Product code
- CL8067702999007
- SKU
- OJUT5ZJ3TD0XR
- Intel® Core™ i3 i3-7100E 2.9 GHz
- 3 MB Smart Cache BGA 1440
- Processor cores: 2 14 nm 64-bit 35 W
- Maximum internal memory supported by processor: 64 GB DDR4-SDRAM
- On-board graphics card Intel® HD Graphics 630
€273.55
(Inc. VAT)
Sold Out
(Delivery 2-4 working days)
Product Info
The Time for a Faster, Smarter PC is Now.
The Time for a Faster, Smarter PC is Now.
Introducing a new tier of PCs, featuring even more powerful performance for seamless computing at home and on-the-go. Work untethered with amazing battery life and experience smooth streaming and brilliant HD entertainment with immersive, full-screen 4K and 360 viewing.
The Speed You Need
Equipped with rapid responsiveness, the 7th generation Intel® Core™ processor has the power and speed to keep up with your demands. Open files and programs quickly, plus seamlessly switch between applications and web pages without delay.
Immersive Entertainment
Experience ultra high-definition content with the clarity and sharpness of 4K resolution.1 Featuring 4x more pixels than full HD screens, you’ll get crisper, clearer images for an immersive viewing like never before.
Hassle Free
Today’s PCs are more hassle-free than ever – log in quickly and easily with facial recognition technology, get 0.5 second wake, and never feel weighed down with new razor-thin devices.
| Processor | |
|---|---|
| Processor manufacturer | Intel |
| Processor generation | 7th gen Intel® Core™ i3 |
| Processor model | i3-7100E |
| Processor base frequency | 2.9 GHz |
| Processor family | Intel® Core™ i3 |
| Processor cores | 2 |
| Processor socket | BGA 1440 |
| Component for | PC |
| Processor lithography | 14 nm |
| Processor series | Intel Core i3-7100 Desktop Series |
| Processor threads | 4 |
| Processor operating modes | 64-bit |
| Processor boost frequency | 2.90 GHz |
| Processor cache | 3 MB |
| Processor cache type | Smart Cache |
| Thermal Design Power (TDP) | 35 W |
| Box | No |
| Cooler included | No |
| Generation | 7th Generation |
| Stepping | B0 |
| Bus type | DMI3 |
| Memory bandwidth supported by processor (max) | 34.1 GB/s |
| Processor codename | Kaby Lake |
| Processor code | SR34V |
| Processor ARK ID | 97131 |
| Memory | |
| Maximum internal memory supported by processor | 64 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 1600,2133 MHz |
| Memory channels | Dual-channel |
| ECC | Yes |
| Graphics | |
| On-board graphics card | Yes |
| On-board graphics card model | Intel® HD Graphics 630 |
| Maximum on-board graphics card memory | 64 GB |
| On-board graphics card outputs supported | Embedded DisplayPort (eDP), DisplayPort, HDMI, DVI |
| On-board graphics card base frequency | 350 MHz |
| On-board graphics card dynamic frequency (max) | 950 MHz |
| Number of displays supported (on-board graphics) | 3 |
| On-board graphics card 4K support | Yes |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card maximum resolution (DisplayPort) | 4096 x 2304 pixels |
| On-board graphics card maximum resolution (eDP - Integrated Flat Panel) | 4096 x 2304 pixels |
| On-board graphics card maximum resolution (HDMI) | 4096 x 2304 pixels |
| On-board graphics card refresh rate at maximum resolution (DisplayPort) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (HDMI) | 30 Hz |
| On-board graphics card ID | 0x591B |
| Features | |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Market segment | Desktop |
| Maximum number of PCI Express lanes | 16 |
| PCI Express slots version | 3.0 |
| PCI Express configurations | 1x16, 2x8, 1x8+2x4 |
| Supported instruction sets | SSE4.1, SSE4.2, AVX 2.0 |
| CPU configuration (max) | 1 |
| Embedded options available | Yes |
| PCI Express CEM revision | 3.0 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G077159 |
| Processor special features | |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® Turbo Boost Technology | No |
| Intel® Quick Sync Video Technology | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Wireless Display (Intel® WiDi) | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Trusted Execution Technology | No |
| Intel® Memory Protection Extensions (Intel® MPX) | Yes |
| Intel® Transactional Synchronization Extensions | No |
| Intel Enhanced Halt State | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel TSX-NI | No |
| Intel® OS Guard | Yes |
| Intel Secure Boot | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel HD Graphics | Yes |
| Intel 64 | Yes |
| Intel Identity Protection Technology version | 1.00 |
| Intel Secure Boot Technology version | 1.00 |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel TSX-NI version | 0.00 |
| Conflict-Free processor | Yes |
| Intel® Boot Guard | Yes |
| Intel® vPro™ Platform Eligibility | No |
| Operational conditions | |
| Tjunction | 100 °C |
| Technical details | |
| Bus type units | GT/s |
| Launch date | Q1'17 |
| Maximum resolution & refresh rate (DisplayPort) | 4096x2304@60Hz |
| Maximum resolution & refresh rate (HDMI) | 4096x2304@30Hz |
| Maximum resolution & refresh rate (Integrated Flat Panel) | 4096x2304@60Hz |
| Maximum resolution & refresh rate (VGA) | N/A |
| Processor cache | 3072 KB |
| Product type | System on Chip |
| Status | Launched |
| Maximum memory | 64 GB |
| Processor brand name | 7th Gen Intel Core i3 processors |
| Supported memory types | DDR4-SDRAM |
| Last change | 63903513 |
| Product family | 7th Generation Intel Core i3 Processors |
| Maximum graphics card memory | 64 GB |
| Processor ID | 0x591B |
| Logistics data | |
| Harmonized System (HS) code | 8542310001 |
| Weight & dimensions | |
| Processor package size | 42mm x 28mm |
| Other features | |
| Maximum internal memory | 64 GB |
| Maximum internal memory | 65536 MB |
| Graphics output | eDP/DP/HDMI/DVI |
