Cisco Catalyst 1300-24FP-4G - Switch - L3 - Managed - 24 x 10/100/1000 (PoE+) + 4 x Gigabit SFP - rack-mountable - PoE+ (370 W)
- Brand
- Cisco
- Product code
- C1300-24FP-4G
- SKU
- AAJHC1XC82ED2
- EAN/GTIN
- 889728521499
- Switch
- L3
- Managed
- 24 x 10/100/1000 (PoE+) + 4 x Gigabit SFP
- rack-mountable
- PoE+ (370 W)
- Weight: 7.10 KG
Product Info
The Cisco Catalyst 1300-24FP-4G switch is part of the fully managed switch line that delivers reliable and secure connectivity for small business networks. These switches accelerate your digital transformation by delivering full Layer 2/3 capabilities, an intuitive web dashboard, advanced networking features, and PoE+ support.
Description
SWITCH PORTS
24 ports 10/100/1000 + 4x 1GE SFP (total PoE power budget: 375W, PoE, PoE+)
SIMPLE
Intuitive Cisco Business mobile app, local web interface, and Cisco Business Dashboard allows you to set up, manage, and monitor the switch, with step-by-step instructions to install and configure your network in minutes - no IT expertise required
ENHANCED SECURITY
IP-MAC port binding detects and blocks deliberate network attacks. IPv6 First Hop Security provides unparalleled protection against a vast range of address spoofing and man-in-the-middle attacks on IPv6 networks
ENERGY EFFICIENT
Optimizes power usage to lower operational cost. Compliant with IEEE 802. 3az Energy Efficient Ethernet. Fanless in select models
PERFECT FOR SMALL BUSINESS
Requires no subscription or licenses to use, and offers limited lifetime hardware warranty with complimentary 1-year technical support
| General | |
|---|---|
| Flash Memory | 512 MB |
| Enclosure Type | Rack-mountable |
| Subtype | Gigabit Ethernet |
| Authentication Method | RADIUS, TACACS+ |
| Encryption Algorithm | SSL, MD5 |
| PoE Budget | 370 W |
| Power Over Ethernet (PoE) | PoE+ |
| Device Type | Switch - 24 ports - L3 - Managed |
| MAC Address Table Size | 16000 entries |
| Ports | 24 x 10/100/1000 (PoE+) + 4 x Gigabit SFP |
| Jumbo Frame Support | 9000 bytes |
| RAM | 1 GB DDR4 SDRAM |
| Processor | X ARM: 1.4 GHz |
| Performance | Forwarding rate (64‑byte packets): 41.66 MppsSwitching capacity: 56 Gbps |
| Capacity | MSTP instances: 8RPVST+ instances: 126Link aggregation groups: 8Link aggregation ports: 8VLAN IDs: 4093IGMP multicast groups: 2000IPv4 routes (static): up to 990IPv4 interfaces: 128ACL rules: 1024Priority queues: 8Packet buffer size: 1.5 MB |
| Compliant Standards | IEEE 802.1x, IEEE 802.3az, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.3ad (LACP), IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, IEEE 802.3af, IEEE 802.3at |
| Status Indicators | System, link/activity/speed, PoE |
| Routing Protocol | STP, static IP routing, RSTP, MSTP, IGMP, IGMPv2, IGMPv3, CIDR, RIP-2, policy-based routing (PBR), MLD, MLDv2, Bounjour |
| Remote Management Protocol | CLI, SNMP, Telnet, SSH, SSH-2, DHCP, SCP, HTTPS, HTTP, ICMP, TFTP, Syslog, SNMP 2c, SNMP 3, RMON, RADIUS |
| Features | 1 fan, VLAN support, STP support, CLI management, ATP, FHS, QoS, sFlow, dynamic routing, Zero-Touch Deployment, Port Security, Web authentication, Address Resolution Protocol, ARP inspection, IP source guard, DHCP snooping, IPMB, NDP, router advertisement guard, DHCPv6 guard, layer 3 routing, LAG, port mirroring, eco-friendly button, EEE, RSTP, MSTP support, PVST+, RPVST+, LACP, Protocol-based VLANs support, MAC based VLAN, VLAN management, Private VLAN, PVE, Guest VLAN, GVRP, CPE VLAN, Auto Surveillance VLAN, MVR, Q-in-Q tunnelling, TPID, GARP, UDLD, DHCP relay, DHCP server, IGMP snooping, IGMP querier, IGMP proxy, HoL Blocking Prevention, loopback detection, ACL support, BOOTP support, UDP, High Availability, MAC address authentication, BPDU Guard, STP Root Guard, STP loop guard, DAI, DoS protection, SCT, SSD, trustworthy systems, Broadcast Storm Control, Multicast Storm Control, Storm Control, Unicast Storm Control, Unknown Storm Control, DoS attack prevention, WRR, ToS, DSCP based CoS, DiffServ support, TCP congestion, iSCSI traffic optimisation, path MTU discovery, DAD, RA guard, MLD snooping, MLD proxy, Telnet server, DNS client, Telnet client, DHCP client, Cisco NG PnP Protocol, IPv4 and IPv6 dual stack, VLAN mirroring, RSPAN, SCP, chip guard, boot integrity, persistent PoE, PoE scheduling, time-based port operation, cable length detection, LLDP, LLDP-MED, reset button |
| Expansion / Connectivity | |
| Interfaces | 24 x 10/100/1000 Base-T (PoE+) RJ-454 x 1000Base-X SFP1 x console RJ-451 x USB-C console |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - lifetime - response time: next business dayTechnical support - consulting - 1 year |
| Miscellaneous | |
| MTBF | 698,220 hours |
| Included Accessories | Pointer card, mounting kit |
| Compliant Standards | Plug and Play, RFC768, RFC783, RFC791, RFC792, RFC793, RFC813, RFC826, RFC879, RFC896, RFC854, RFC855, RFC856, RFC858, RFC894, RFC919, RFC920, RFC922, RFC950, RFC951, RFC1042, RFC1071, RFC1123, RFC1141, RFC1155, RFC1157, RFC1213, RFC1215, RFC1286, RFC1350, RFC1442, RFC1451, RFC1493, RFC1533, RFC1541, RFC1542, RFC1573, RFC1624, RFC1643, RFC1700, RFC1757, RFC1867, RFC1907, RFC2011, RFC2012, RFC2013, RFC2030, RFC2131, RFC2132, RFC2233, RFC2576, RFC2616, RFC2618, RFC2665, RFC2666, RFC2674, RFC2737, RFC2819, RFC2863, RFC3164, RFC3176, RFC3411, RFC3412, RFC3413, RFC3414, RFC3415, RFC3416, RFC4330, RFC4443, RFC4291, RFC2460, RFC4861, RFC4862, RFC1981, RFC4007, RFC3484, RFC5214, RFC4293, RFC3595, CSA 22.2, FCC CFR47 Part 15, UL 62368, WEEE |
| Power | |
| Power Device | Internal power supply |
| Voltage Required | AC 100-240 V (50 - 60 Hz) |
| Environmental Parameters | |
| Min Operating Temperature | -5 °C |
| Max Operating Temperature | 50 °C |
| Max Storage Temperature | 70 °C |
| Min Storage Temperature | -25 °C |
| Humidity Range Operating | 5 - 90% RH (non-condensing) |
| Humidity Range Storage | 5 - 90% RH (non-condensing) |
| Dimensions & Weight | |
| Width | 44.5 cm |
| Height | 4.4 cm |
| Depth | 34.5 cm |
| Weight | 4.6 kg |
