Synology SA3610 - NAS server - 12 bays - rack-mountable - SATA 6Gb/s / SAS - RAID RAID 0, 1, 5, 6, 10, JBOD, RAID F1 - RAM 16 GB - Gigabit Ethernet / 10 Gigabit Ethernet - iSCSI support - 2U
- Brand
- Synology
- Product code
- SA3610
- SKU
- 8A806GJL62CBQ
- EAN/GTIN
- 4711174725038
- Supercharged performance - efficient handling of data-intensive applications with over 6,200/3,000 MB/s sequential read/write throughput
- Petabyte-scale flexibility - attach up to 7 additional Synology RX1222sas expansion units for up to 96 drive bays
- Flexible networking options - leverage built-in 10GbE RJ-45 ports or boost network bandwidth with 10/25/40GbE and fiber channel adapters
- High service availability - minimize downtime with Synology high availability active-passive clustering and out-of-band (OOB) management
Description
Dependable platform for scalable data management
The extensive scaling capabilities of the SA3600 series enable enterprise data centers, large production studios, and growing businesses to meet their increasing data storage needs by accessing over 1 PB of raw storage capacity on demand. SA3610 delivers stable high throughput, perfect for smooth ingestion of large data volumes, including backups, and video recording or serving tasks. Hardware and software safeguards ensure maximum data and service availability, as well as reliable recovery options in case of disaster or attack.
Designed to keep data available and services online
Built-in solutions help maintain high system availability and facilitate fast recovery if a disaster or major outage occurs.
Powerful sharing and collaboration tools for teams
Synology's collaboration suite provides a private cloud solution for on-site and remote workers to concurrently edit documents, share files, manage emails, send instant messages, and more.
Certified storage for virtualization and containerization
SA3000 Series units can serve as virtual machine storage, VM backup servers, and alternative container or VM hosts. They are fully certified as storage for VMware vSphere, Microsoft Hyper-V, Citrix XenServer, and OpenStack environments.
| General | |
|---|---|
| Device type | NAS server |
| Host Connectivity | Gigabit Ethernet / 10 Gigabit Ethernet |
| Enclosure Type | Rack-mountable - 2U |
| Total storage capacity | 0 TB |
| Max Supported Capacity | 1.728 PB |
| Installed Devices / Modules Qty | 0 (installed) / 12 (max) |
| Width | 43.05 cm |
| Depth | 69.2 cm |
| Height | 8.8 cm |
| Weight | 14.5 kg () |
| Built-in Devices | Led panel |
| Processor / Memory | |
| Processors Installed | 1 x Intel Xeon D-1567 2.1 GHz |
| Number of Cores | 12-core |
| Max Supported Qty | 1 |
| Max Turbo Speed | 2.7 GHz |
| RAM | 16 GB (installed) / 128 GB (supported) - DDR4 |
| Features | Registered, ECC |
| Storage Controller | |
| Type | RAID |
| Interface type | SATA 6Gb/s / SAS |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD, RAID F1 |
| Networking | |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, 1GbE, 10GbE |
| Network / Transport Protocol | PPTP, L2TP, iSCSI, FTP, SMB, NFS, OpenVPN |
| Remote Management Protocol | SNMP, Telnet, SSH, LDAP |
| Network Services Compatibility | File Level Security (ACLs), Network File System (NFS), FTP, Apple File Protocol (AFP), Web-based Distributed Authoring and Versioning (WebDAV), Calendaring Extensions to WebDAV (CalDAV) |
| Performance | Sequential read:6275 Mbps Sequential write:3056 Mbps Random read:450814 IOPS Random write:122675 IOPS Local user account:16000 Local group account:512 Maximum number of shared folders:512 Maximum concurrent connections:4000 |
| Features | Firewall protection, VPN support, wake on LAN (WOL), B-tree file system (Btrfs), EXT4 file system, Rsync compatible, wake on WAN (WOW), Let's Encrypt, SSD read-write cache, shared folder encryption, SMB encryption, login auto block, Kubernetes support |
| Encryption Algorithm | SSL, TLS |
| Expansion / Connectivity | |
| Expansion Bays | 12 (total) / 12 (free) x hot-swap - 2.5" / 3.5" |
| Expansion slots | 2 (total) / 2 (free) x PCI Express 3.0 x8 X M.2 |
| Interfaces | 2 x USB 3.2 Gen 1 - Type A 1 x expansion port - Mini-SAS HD (SFF-8644) 1 x Ethernet 1000Base-T (management) - RJ-45 2 x Ethernet 10Gb - RJ-45 4 x Ethernet 1000Base-T - RJ-45 |
| Miscellaneous | |
| Features | Scheduled power on/off, built-in 4 x 80 mm cooling fans |
| Compliant Standards | RoHS |
| Included Accessories | Accessory pack, 2 x power cables |
| Power | |
| Power Device | Internal power supply |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Power Redundancy | Yes |
| Power Redundancy Scheme | 1+1 |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Software / System Requirements | |
| Storage Operating System | Synology DiskStation Manager |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 35 °C |
| Humidity Range Operating | 8 - 80% RH |
