Tripp Lite IS1800HGDV isolation transformer
Isolator Series Dual-Voltage 115/230V 18
- Brand
- Eaton
- Product code
- IS1800HGDV
- SKU
- MKBMD90X9MUCQ
- Protects sensitive equipment from EMI/RFI line noise and surges
- Cumulative leakage current less than 100 µA
- Automatically shuts down all outlets in case of overload
- Offers complete isolation from input AC mains power
- Ideal for use in any industrial, network or medical environment
€1632.75
(Inc. VAT)
Sold Out
(Delivery 2-4 working days)
Product Info
| Features | |
|---|---|
| AC inlet type | C20 coupler |
| AC outlet types | C13 |
| AC outlets quantity | 8 AC outlet(s) |
| AC input voltage | 115 - 230 V |
| AC input frequency | 50 - 60 Hz |
| Input current (max) | 15 A |
| Short circuit protection | Yes |
| Load capacity | 1800 VA |
| Housing colour | White |
| Certification | ANSI/AAMI ES60601-1:2005+A2+A1, IEC60601-1 3RD EDITION +A1, cAN/CSA-C22.2 NO. 60601-1:14, CE, NOM |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 50 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating altitude | 0 - 3000 m |
| Weight & dimensions | |
| Width | 300 mm |
| Depth | 350 mm |
| Height | 140 mm |
| Weight | 23.5 kg |
| Package width | 445 mm |
| Package depth | 500.1 mm |
| Package height | 279.9 mm |
| Package weight | 23.5 kg |
| Logistics data | |
| Products per master (outer) case | 1 pc(s) |
| Master (outer) case width | 445 mm |
| Master (outer) case length | 500.1 mm |
| Master (outer) case height | 279.9 mm |
| Master (outer) case gross weight | 23.2 kg |
| Country of origin | Taiwan |
