Crestron Room Scheduling Touch Screen TSS-770-B-S-LB KIT - Room manager - wireless, wired - Bluetooth, 802.11a/b/g/n/ac - 2.4 Ghz, 5 GHz - 10/100 Ethernet - smooth black
- Brand
- CRESTRON ELECTRONICS
- Product code
- TSS-770-B-S-LB KIT
- SKU
- 5BYBDMAJH2G7S
- Functional
- Reliable
- Secure
- Manageable
- Cost-effective
Description
Functional
The TSS-770 provides everything needed for scheduling applications in one compact unit that mounts over a standard electrical box or cutout. The TSS-770 offers high-speed Ethernet and PoE/PoE+ connectivity, or, for deployments without access to Ethernet, it can be connected the network over Wi-Fi communications via a local wireless access point (WAP).
Reliable
Consumer tablets are meant for mobile handheld use and not permanent installs. By contrast, Crestron touchscreens are purpose-built for permanent installation and years of reliable 24/7 operation in a commercial environment.
Secure
Crestron touchscreens employ enterprise-grade networking with robust security features such as 802.1X authentication, TLS encryption, HTTPS connectivity, and Active Directory service integration. These features protect your network against service interruptions and malicious intrusions and ensure compliance with your organization's network policies.
Manageable
Crestron touchscreens feature cloud-based provisioning and management to streamline the process of configuring and monitoring every touchscreen on the network and keeping them updated. They also support SNMP, so they can be monitored by your IT administrator alongside every other device on the network.
Cost-effective
Crestron touchscreens offer clear advantages over other alternatives, but that doesn't mean they cost more. The TSS-770 series delivers a comparable or lower cost solution compared to buying tablets with all the extra peripherals and maintenance they require.
General | |
---|---|
Product type | Room manager |
Integrated Components | Speaker, Bluetooth proximity detection beacon |
Integrated sensors | Proximity sensor |
Power source | PoE |
Package Content | TSW-770-LB-B-S light bar |
Connectivity technology | Wireless, wired - Ethernet, Fast Ethernet, Bluetooth, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
Max Range Open Space | 15 m |
Frequency band | 2.4 GHz, 5 GHz |
Display | 7" - LED - colour |
Display resolution | 1280 x 800 pixels |
Interfaces Details | LAN/power 2 x USB 2.0 |
Features | Wall mountable, reset button, surface mountable, capacitive touch screen, auto brightness control, PoE+, DHCP support, power over Ethernet (PoE), auto-negotiation, IPv6 support, half duplex mode, full duplex mode, SSH support, PoE+, IPv4 support, cloud managed, SNMP support |
Control Unit | |
Input type | Touch screen |
Miscellaneous | |
Included Accessories | Mounting kit |
Product Material | Plastic |
Colour | Smooth black |
Encryption Algorithm | AES, 128-bit WEP, 64-bit WEP, SSL, TLS, TKIP, WPA, WPA2-PSK |
Compliant Standards | FCC Part 15 B, IC, IEEE 802.3af, IEEE 802.3at, IEEE 802.1x |
Dimensions & Weight | |
Width | 18.5 cm |
Depth | 5.7 cm |
Height | 10.6 cm |
Weight | 400 g |
Environmental Parameters | |
Min Operating Temperature | 5 °C |
Max Operating Temperature | 40 °C |
Humidity Range Operating | 10 - 90% (non-condensing) |
