HPE MR416i-p Gen10+ Controller - Storage controller (RAID) - 16 Channel - SATA 6Gb/s / SAS 12Gb/s / PCIe 4.0 (NVMe) - RAID 0, 1, 5, 6, 10, 50, 60 - PCIe 4.0 x8 - for ProLiant DL325 Gen10, DL345 Gen10, DL360 Gen10, DL365 Gen10, DL380 Gen10, DL385 Gen10
- Brand
- Hewlett Packard Enterprise
- Product code
- P06367-B21
- SKU
- JWLSF3FRWH3RO
- EAN/GTIN
- 190017298498
- Powerful performance
- 2nd generation tri-mode SerDes
- Enhanced security
Description
Powerful performance
Broadcom MegaRAID Storage Controllers for HPE Gen10 Plus feature Broadcom MR416i controllers with impressive performance including up to 13,700 Mbs of bandwidth, 3M random read IOPS, and 240K RAID5 random write IOPS.
2nd generation tri-mode SerDes
Broadcom MegaRAID Storage Controllers for HPE Gen10 Plus is enabled with SerDes for exceptional support of NVMe4/SAS3/SATA protocols. With tri-mode support, achieve the scalability and flexibility you need for shifting business environments.
Enhanced security
Broadcom MegaRAID Storage Controllers for HPE Gen10 Plus is built with the HPE Silicon Root of Trust for firmware authentication and support for self-encrypting drives to help ensure protection for data at rest and prevention of malware.
| General | |
|---|---|
| Device type | Storage controller (RAID) - plug-in card |
| Host Bus | PCIe 4.0 x8 |
| Storage Controller | |
| Interface | SATA 6Gb/s / SAS 12Gb/s / PCIe 4.0 (NVMe) |
| Buffer size | 4 GB |
| Supported devices | Disk array (RAID) |
| Channel Qty | 16 |
| Max Storage Devices Qty | 240 |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
| Expansion / Connectivity | |
| Interfaces | SATA 6Gb/s / SAS 12Gb/s / PCIe 4.0 (NVMe) |
| Connections | 1 x PCIe 4.0 x8 |
| Software / System Requirements | |
| Software included | StorCLI, HII (UEFI Human Interface Infrastructure), UEFI System Utilities (storage configuration), MegaRAID Storage Administrator, Redfish (Inventory and Events) |
| OS Required | SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, CentOS, Ubuntu, VMware ESXi |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts - 3 years |
| Dimensions & Weight | |
| Depth | 15.7 cm |
| Weight | 146 g |
| Compatibility Information | |
| Designed For | HPE ProLiant DL325 Gen10 Plus V2, DL325 Gen10 Plus V2 Base, DL325 Gen10 Plus V2 Performance, DL345 Gen10 Plus, DL345 Gen10 Plus Base, DL345 Gen10 Plus Entry, DL360 Gen10 Plus, DL360 Gen10 Plus All-NVMe Server for Software Defined Storage, DL360 Gen10 Plus for Weka Base Tracking, DL360 Gen10 Plus Network Choice, DL365 Gen10 Plus, DL380 Gen10 Plus, DL380 Gen10 Plus Network Choice, DL385 Gen10 Plus (v2), DL385 Gen10 Plus Entry (v2) |
