Lenovo
7Y49A03XEA+WIN SERVER2019 ESSENTIAL
K/ThinkSystem ST50 Win Server bundle
- Brand
- Lenovo
- Product code
- 7Y49A03XEA+WIN SERVER2019 ESSENTIAL
- SKU
- LEVWH05O9R25F
€2248.5
(Inc. VAT)
Sold Out
(Delivery 2-4 working days)
Product Info
The Lenovo ThinkSystem ST50 provides an easily manageable, ideal first server for a small-to-medium-sized business, and remote or branch office, or retail environments looking to increase productivity. The space-saving form factor and dynamic capabilities of the ST50 make it well suited for day-to-day computing, file management, printing, email, and web serving in distributed environments. Highly efficient fans keep the server cool and reduce noise in an office environment.
Specifications
Monitor
Monitor Type
None.
General
Front Accessible Bays Qty
1
Type
Server
Internal Bays Qty
4
Server Scalability
1-way
Product Form Factor
Tower - 4U
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Region: EMEA
Processor / Chipset
CPU Qty
1
Max CPU Qty
1
Clock Speed
3.5 GHz
Number of Cores
Quad-Core
Max Turbo Speed
4.7 GHz
Chipset Type
Intel C246
CPU
Intel Xeon E-2224G
Power
Device Type
Power supply
Power Provided
250 Watt
80 PLUS Certification
80 PLUS Platinum
Voltage Required
AC 120/230 V (50/60 Hz)
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 80%
Cache Memory
Installed Size
8 MB
Cache Per Processor
8 MB
Storage Controller
Channel Qty
4
Type
1 x RAID
RAID Level
RAID 0, RAID 1, RAID 5, RAID 10, JBOD
Controller Interface Type
SATA 6Gb/s
Dimensions & Weight
Width
17.5 cm
Weight
7.5 kg
Height
37.5 cm
Depth
40.7 cm
Networking
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Compliant Standards
DASH 1.1
Ethernet Controller
Intel I219-LM
Features
Wake on LAN (WoL), Teaming support, Intel Active Management Technology (AMT) 12
Sustainability Information
ENERGY STAR Certified
Yes
ENERGY STAR Version
2.1
Manufacturer Warranty
Service & Support
Limited warranty - 1 year - on-site - response time: next business day
RAM
Configuration Features
1 x 8 GB
Features
Unbuffered, mixing of different types of memory modules is not supported
Installed Size
8 GB (installed) / 64 GB (max)
Effective Memory Speed
2666 MHz
Rated Memory Speed
2666 MHz
Form Factor
DIMM 288-pin
Technology
DDR4 SDRAM - ECC
Slots
4 (Total) / 3 (empty)
Optical Storage
Type
DVD-Writer
Hard Drive
Type
HDD
Capacity
2 x 1 TB
Interface Type
SATA 6Gb/s
Graphics Controller
Video Interfaces
DisplayPort
Graphics Processor
Intel UHD Graphics P630
Operating System / Software
OS Provided
No operating system
Miscellaneous
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), padlock loop
Security Slot Type
Kensington security slot
Compliant Standards
TUV GS, BSMI, EN 61000-3-2, EN 61000-3-3, EN55024, CB, CCC, IEC 60950-1, EN 60950-1, FCC CFR47 Part 15 B, GB 17625.1, GB 9254 Class A, CECP, GB 4943.1, BIS, NOM-019, EK1-ITB2000, CNS 13438 Class A, KN35, ICES-003 issue 6 Class A, AS/NZS CISPR 32 Class A, KN32 Class A, CNS 14336-1, EN 62368-1, IEC 62368-1, EN 55032 Class A, CISPR 32 Class A, TR CU 020/2011, TR CU 004/2011, UL 62368-1, ASHRAE Class A2, CELP, VCCI 32
Expansion / Connectivity
Bays
1 (total) / 0 (free) x external 5.25" x 1/6H (Slim Line)4 (total) / 2 (free) x internal 3.5"
Slots
1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, full-height1 (total) / 1 (free) x PCIe 3.0 x1 - half-length, full-height1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, full-height (x4 mode)
Interfaces
4 x USB 3.1 Gen 1 (2 front, 2 rear)2 x USB 2.02 x DisplayPort1 x LAN (Gigabit Ethernet)1 x serial1 x audio line-out
