Cisco Business 140AC - Radio access point - Wi-Fi 5 - 2.4 GHz, 5 GHz
- Brand
- Cisco
- Product code
- CBW140AC-E
- SKU
- L4CJYC4Q1BRVN
- EAN/GTIN
- 889728276054
- Radio access point
- Wi-Fi 5
- 2.4 GHz, 5 GHz
- Weight: 0.96 KG
Product Info
The Cisco Business 140AC Access Point delivers powerful multi-user, multiple input, multiple output (MU-MIMO) (2x2) wireless in a compact form factor. Ideal for indoor Wi-Fi coverage, the Cisco Business 140AC delivers a highly secure and reliable wireless connection for small business workplaces.
Compatible with Cisco Business 100 Series Mesh Extenders to rapidly expand your Wi-Fi network.
Description
PERFORMANCE
Enterprise-grade MU-MIMO (2x2) performance delivering highly secure and reliable wireless connectivity for small businesses
DEPLOYMENT
Flexible deployment wall or celling mount (brackets included). Works also with Cisco Business Power over Ethernet injector (CB-PWRINJ)
FLEXIBILITY
Mix and match with Cisco Business Wireless access points and mesh extenders to increase your Wi-Fi coverage
SET UP IN MINUTES
Simplify management and monitor your network from Cisco Business Mobile app or web browser
ADVANCED SECURITY
Enterprise-class security prevent malware, phishing, and other threats from compromising your network via Cisco Umbrella integration
| General | |
|---|---|
| Height | 3.3 cm |
| Device Type | Radio access point |
| Weight | 400 g |
| Width | 15.08 cm |
| Depth | 15.08 cm |
| Expansion / Connectivity | |
| Interfaces | 1 x 1000Base-T (PoE) - RJ-45 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - replacement - lifetime |
| Networking | |
| Form Factor | External |
| Connectivity Technology | Wireless |
| Data Transfer Rate | 1 Gbps |
| Status Indicators | Status |
| Frequency Band | 2.4 GHz, 5 GHz |
| Authentication Method | RADIUS, MS-CHAP v.2, Extensible Authentication Protocol (EAP), EAP-FAST |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2 |
| Performance | Maximum data rate (2.4 GHz): 300 MbpsMaximum data rate (5 GHz): 867 Mbps |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11d, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11h, IEEE 802.11n, IEEE 802.11r, IEEE 802.11ac Wave 2 |
| Encryption Algorithm | AES, TLS, PEAP, TTLS, WPA2, WPA3 |
| Capacity | Wireless clients per Wi-Fi radio: 200Wireless clients: 400VLANs supported: 16 |
| Features | VLAN support, manageable, DFS support, wall mountable, Mesh networking, Wi-Fi Multimedia (WMM) support, RADIUS support, ceiling mountable, 802.1x authentication, MU-MIMO technology, SU-MIMO technology, Authentication, Authorization and Accounting (AAA) |
| Miscellaneous | |
| Compliant Standards | VCCI, ICES-003, FCC Part 15.247, RSS-102, UL 2043, UL 60950-1, IEC 60950-1, EN 60950-1, FCC Part 15.107, FCC Part 15.109, FCC Part 15.407, ARIB STD-T66, ARIB STD-T71, EN 300 328, EN 50385, FCC OET Bulletin 65c, EN 301 489-1, RSS-247, EN 301 893, CAN/CSA-C22.2 No. 60950-1, EMI Class B, EN 301 489-17 |
| Included Accessories | Torx security screw, ceiling rail mount clip, mounting bracket |
| Power | |
| Power Consumption Operational | 8.3 Watt |
| Power Over Ethernet (PoE) Supported | PoE |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Processor / Memory / Storage | |
| Flash Memory | 256 MB |
| RAM | 1 GB |
| Processors Installed | 710 MHz |
| Aerial | |
| Antenna | Internal |
