Cisco Catalyst IE3300 Rugged Series
Cisco Catalyst IE3300 Rugged Series - Network Advantage - switch - Managed - 10 x 10/100/1000 (8 PoE+) + 2 x SFP - DIN rail mountable - PoE+ (360 W) - DC power
- Brand
- Cisco IOT
- Product code
- IE-3300-8P2S-A
- SKU
- 6WKXTW1ZB7AZ0
- EAN/GTIN
- 889728205344
- Built for harsh environments and wide temperature ranges
- Fanless, convection-cooled with no moving parts for extended durability
- Hardened for vibration, shock and surge, and electrical noise immunity
- Improves uptime, performance, and safety of industrial systems and equipment
€9476.58
(Inc. VAT)
Sold Out
(Delivery 2-4 working days)
| General | |
|---|---|
| Device type | Switch - 10 ports - Managed |
| Enclosure Type | DIN rail mountable |
| Subtype | Gigabit Ethernet |
| Ports | 10 x 10/100/1000 (8 PoE+) + 2 x SFP |
| Power over Ethernet (PoE) | PoE+ |
| PoE Budget | 360 W |
| Capacity | Queues:8 IGMP multicast groups:1000 VLAN IDs:256 STP instances:128 |
| Routing Protocol | IGMPv2, IGMP, IGMPv3 |
| Remote Management Protocol | SNMP, SNMP 3, SSH, SCP, NTP, DHCP |
| Authentication method | RADIUS, TACACS+ |
| Features | IGMP snooping, Syslog support, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, Dying Gasp support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, DHCP server, Dynamic ARP Inspection (DAI), Per-VLAN Spanning Tree Plus (PVST+), Uni-Directional Link Detection (UDLD), LLDP support, Remote Switch Port Analyzer (RSPAN), Flexible NetFlow (FNF), IGMP filtering, Storm Control, IP source guard, Resilient Ethernet Protocol (REP), SmartPort technology, rate limit, IGMP querier, Voice VLAN, Guest VLAN, Inter-VLAN Routing, Switched Port Analyzer (SPAN), VLAN Trunking Protocol (VTP) v.3, BPDU Guard, VLAN Trunking Protocol (VTP) v.2 |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 1588v2 |
| RAM | 2 GB |
| Flash memory | 1.5 GB |
| Built-in Devices | SD card reader |
| Expansion / Connectivity | |
| Interfaces | 10 x 10/100/1000 Base-T RJ-45 8 ports (PoE+) 2 x SFP 3 x alarm 1 x serial (RS-232) RJ-45 console 1 x console mini-USB |
| Power | |
| Power Device | Internal power supply |
| Voltage Required | DC 9.6 - 60 V (non-PoE) / 54 V (PoE+) / 48 V (PoE) |
| Power Consumption Operational | 35 Watt |
| Miscellaneous | |
| MTBF | 611,350 hours |
| Compliant Standards | EN55024, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, ICES-003 Class A, EN 61000-4-5, EN 61000-6-2, EN 61000-4-8, IEC 60950-1, EN 61000-6-4, IEC 60068-2-30, IEC 60068-2-27, EN 61326-1, EN 61000-4-16, EN 61000-4-29, IEC 60068-2-14, IEC 60068-2-78, MIL-STD-810, EN 50121-4, IP30, VCCI Class A, CISPR 11 class A, EN 61000-4-10, EN 61000-4-18, IEC 61850-3, FCC CFR47 Part 15 B Class A, IEEE 1613, CNS 13438 Class A, EN 300 386, KN35, UL/CSA60950-1, AS/NZS CISPR 32 Class A, KN32 Class A, IEC 62368-1, IEEE 1588, EN 60068-2-52, EN 60068-2-60, UL 62368-1, EN 60079-15, IEC 60079-0, IEC 60079-15, EN 60079-0, EN 55032/CISPR 32 Class A, CISPR 35, EN 61000-4-17, UL 121201, EN 61850-3, UL/CSA 61010-2-201, IEC/EN 61010-2-201, UL/CSA 60079-0, UL/CSA 60079-15 |
| Dimensions & Weight | |
| Width | 9.14 cm |
| Depth | 13.5 cm |
| Height | 15.2 cm |
| Weight | 1.7 kg |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Environmental Parameters | |
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 60 °C |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 85 °C |
