Cisco Catalyst 9300
C9300-24S-E - 889728192668
Cisco Catalyst 9300 - Network Essentials - switch - L3 - Managed - 24 x Gigabit SFP - rack-mountable
- Brand
- Cisco
- Product code
- C9300-24S-E
- SKU
- ZX73RVMTA5Z88
- EAN/GTIN
- 889728192668
- Cloud ready
- Optimized for mobility
€24736.68
(Inc. VAT)
Sold Out
(Delivery 2-4 working days)
Description
Cloud ready
Simplify, secure, and transform your cloud environment. Cisco delivers a digital-ready approach that starts at the edge and extends to where applications reside.Optimized for mobility
Catalyst 9300 series access switches give you smart, simple, and highly secure unified access.Specifications
General
Device type
Switch - 24 ports - L3 - Managed - stackable
Enclosure Type
Rack-mountable 1U
Subtype
Gigabit Ethernet
Ports
24 x Gigabit SFP
Performance
Switching capacity:128 Gbps Stacking bandwidth:480 Gbps Forwarding rate:154.76 Mpps
Capacity
IPv4 routing table entries:32000 IPv6 routing table entries:16000 Flexible NetFlow entries:64000 VLAN IDs:4000 Switched virtual interfaces (SVIs):2000
MAC Address Table Size
32000 entries
Jumbo Frame Support
9198 bytes
Routing Protocol
OSPF, IS-IS, RIP-1, RIP-2, IGMP, VRRP, PIM-SM, OSPFv3, PIM-SSM, policy-based routing (PBR), RIPng
Remote Management Protocol
SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF
Encryption Algorithm
128-bit AES
Features
Trunking, full duplex mode, Weighted Random Early Detection (WRED), Spanning Tree Protocol (STP) support, Access Control List (ACL) support, Quality of Service (QoS), Remote Switch Port Analyzer (RSPAN), Management Information Base (MIB), Cisco StackWise-480 technology, Cisco StackPower technology, Flexible NetFlow (FNF), 802.1x authentication, 16MB packet buffer, FTP client, 3 fans, Control plane protection (CoPP), Source-Specific Multicast (SSM), integrated Wireshark, VLAN Double Tagging (Q-in-Q), Private VLAN
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s
RAM
8 GB
Flash memory
16 GB
Status Indicators
Status
Expansion / Connectivity
Interfaces
24 x Gigabit LAN SFP 1 x USB 2.0
Expansion slots
1 (total) / 1 (free) x Expansion Slot
Power
Power Device
Internal power supply - hot-plug
Installed Qty
2
Max Supported Qty
2
Power Redundancy
Yes
Power Provided
715 Watt
Voltage Required
AC 120/230 V (50 - 60 Hz)
Miscellaneous
MTBF
284,130 hours
Compliant Standards
CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN50082-1, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, CCC, ICES-003 Class A, EN 61000-4-5, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Class A, VCCI Class A, EN 55022 Class A, FCC CFR47 Part 15 A, EN 300 386, TVCN 7317, VCCI V-3/2009 Class A, CAN/CSA-C22.2 No. 60950-1
Software / System Requirements
Software included
Cisco ONE StealthWatch License Term - 25 Flow Licenses, 25 x Cisco ONE ISE BASE Tracker Licences Term (5 years), 25 x Cisco ONE ISE PLUS Tracker Licences Term (5 years), Network Plug-n-Play License
OS Required
Cisco IOS Universal
Dimensions & Weight
Width
44.4 cm
Depth
48.8 cm
Height
4.3 cm
Weight
7.64 kg
Manufacturer Warranty
Service & Support
Limited warranty - replacement - lifetime - response time:next business day Technical support - consulting - 90 days
Environmental Parameters
Min Operating Temperature
-5 °C
Max Operating Temperature
45 °C
Humidity Range Operating
5 - 90% (non-condensing)
Min Storage Temperature
-40 °C
Max Storage Temperature
70 °C
Humidity Range Storage
5 - 90% (non-condensing)
