Synology FlashStation FS6400 - NAS server - 24 bays - rack-mountable - RAID RAID 0, 1, 5, 6, 10, JBOD, RAID F1 - RAM 32 GB - Gigabit Ethernet / 10 Gigabit Ethernet - iSCSI support - 2U
- Brand
- Synology
- Product code
- FS6400
- SKU
- YBJIJ089CVRRO
- EAN/GTIN
- 4711174722730
- Fast and reliable networking
- Complete iSCSI and virtualization solutions
- Next-generation file system for better data protection
- RAID F1
Description
Fast and reliable networking
With multi-LAN design, FS6400 is capable of performing Link Aggregation and failover.
Complete iSCSI and virtualization solutions
Synology iSCSI storage supports most virtualization solutions such as VMware vSphere, Microsoft Hyper-V, Citrix Xen Server, and OpenStack Cinder to enhance work efficiency.
Next-generation file system for better data protection
The Btrfs file system introduces advanced storage technologies and optimized snapshots to prevent data corruption and reduce maintenance overheads. It offers flexible, efficient data protection and recovery tools while ensuring high-level data integrity.
RAID F1
Due to the peculiarities of SSD and RAID technology, a common challenge lies in how to prevent all of the drives from failing at the same time because of the evenly distributed workload. RAID F1 alleviates this problem with a specially designed algorithm to unevenly distribute workload to drives, enhancing the resilience of the storage pool and ensuring your data remains safe.
| General | |
|---|---|
| Device type | NAS server |
| Host Connectivity | Gigabit Ethernet / 10 Gigabit Ethernet |
| Enclosure Type | Rack-mountable - 2U |
| Total storage capacity | 0 GB |
| Installed Devices / Modules Qty | 0 (installed) / 24 (max) |
| Width | 48.2 cm |
| Depth | 72.4 cm |
| Height | 8.8 cm |
| Weight | 17.26 kg () |
| Processor / Memory | |
| Processors Installed | 2 x Intel Xeon Silver 4110 2.1 GHz |
| Number of Cores | 8-core |
| Max Turbo Speed | 3 GHz |
| RAM | 32 GB (installed) / 512 GB (supported) - DDR4 |
| Features | Registered, ECC |
| Storage Controller | |
| Type | RAID |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD, RAID F1 |
| Networking | |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, 1GbE, 10GbE |
| Network / Transport Protocol | PPTP, L2TP, iSCSI, SMTP, FTP, SMB, HTTPs |
| Remote Management Protocol | SNMP, Telnet, HTTPS, SSH, SMTP, LDAP |
| Network Services Compatibility | Microsoft Active Directory (AD), Network File System (NFS), FTP, Server Message Block (SMB), Apple File Protocol (AFP), HTTPS, Web-based Distributed Authoring and Versioning (WebDAV), Calendaring Extensions to WebDAV (CalDAV) |
| Features | Firewall protection, VPN support, LDAP support, wake on LAN (WOL), antivirus analysis, High Availability, anti-malware protection, Access Control List (ACL) support, e-mail server, reset button, bandwidth control, surveillance station, VPN Server, failover protection, OpenStack compatible, B-tree file system (Btrfs), file station, EXT4 file system, iSCSI LUN clone/snapshot, Windows ODX, MailPlus server |
| Encryption Algorithm | AES-NI |
| Security DVR | |
| IP Cameras Supported | 128 |
| Compression Format | MJPEG, H.264, H.265 |
| Image Resolution | 1280x720, 1920x1080, 2048x1536, 2591x1944, 3840x2160 |
| Expansion / Connectivity | |
| Expansion Bays | 24 (total) / 24 (free) x hot-swap - 2.5" |
| Expansion slots | 2 x PCI Express 3.0 x8 16 (total) / 14 (free) x DIMM 288-pin |
| Interfaces | 2 x Ethernet 1000Base-T - RJ-45 2 x USB 3.0 - Type A 1 x serial - DB-9 2 x Ethernet 10Gb - RJ-45 |
| Miscellaneous | |
| Features | Built-in 4 cooling fans |
| Compliant Standards | VCCI, BSMI, FCC, RoHS, EAC, RCM |
| Included Accessories | Accessory pack |
| Power | |
| Power Device | Internal power supply |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Power Redundancy | Yes |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 288.49 Watt |
| Power Provided | 800 Watt |
| Software / System Requirements | |
| OS Required | Microsoft Windows 7 or later, Apple MacOS X 10.11 or later |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 35 °C |
| Humidity Range Operating | 5 - 95% |
| Sound Emission | 53.7 dBA |
