Cisco Catalyst 9200L - Network Essentials - switch - L3 - Managed - 48 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+ - rack-mountable - PoE+
- Brand
- Cisco
- Product code
- C9200L-48P-4X-E
- SKU
- MBW82UZB6MYPS
- EAN/GTIN
- 889728170192
- Network Essentials
- switch
- L3
- Managed
- 48 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+
- rack-mountable
- PoE+
- Weight: 7.90 KG
Product Info
The Cisco Catalyst 9200 Series switches extend the power of intent-based networking and Catalyst 9000 hardware and software innovation to a broader set of deployments. With its family pedigree, Catalyst 9200 Series switches offer simplicity without compromise – it is secure, always on, and IT SIMPLIFIED.
Description
CONFIGURATION
48 x 10/100/1000M Ethernet with PoE+, 4 x 10G SFP+ uplinks, 740W total PoE budget
IT SIMPLIFIED
Catalyst 9200 Series switches simplify complexity, optimize IT, and reduce operational costs with Cisco UADP ASIC and Cisco IOS XE providing consistency, intelligence and automation
SECURE
Enhanced security with MACsec encryption, full flexible NetFlow, and trustworthy solutions that protect the integrity of the hardware as well as the software and all data that flows through the switch
ALWAYS-ON
Differentiated resiliency with Field-Replaceable Units (FRU) and redundant power supplies, redundant fans, 80 Gbps backplane stacking, and layer 3 support
MANAGEMENT
Choice of CLI, Cisco Catalyst Center (formerly Cisco DNA Center) on-premises management, or cloud monitoring for Catalyst on Meraki dashboard
| General | |
|---|---|
| Enclosure Type | Rack-mountable |
| RAM | 2 GB |
| Flash Memory | 4 GB |
| Subtype | Gigabit Ethernet |
| Power Over Ethernet (PoE) | PoE+ |
| Built-in Devices | RFID tag |
| Device Type | Switch - 48 ports - L3 - Managed |
| Ports | 48 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+ |
| Jumbo Frame Support | 9198 bytes |
| Remote Management Protocol | SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, NETCONF, RESTCONF |
| Performance | Stacking bandwidth: 80 GbpsSwitching capacity: 176 GbpsForwarding rate: 261.9 Mpps |
| Capacity | Virtual networks: 1MAC addresses: 16000IPv4 routes: 11000IPv4 routing table entries: 3000IPv6 routing table entries: 1500Multicast scale: 1000ACL scale entries: 1500FNF entries: 16000Switched virtual interfaces (SVIs): 512Queues per port (egress): 8 |
| Routing Protocol | OSPF, RIP, VRRP, policy-based routing (PBR), MSTP |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at, IEEE 802.3bz |
| Features | EIGRP Stub Routing, Rapid PVST+, SRR, RSPAN, CoS, FNF, DSCP support, MACsec support, 6MB packet buffer, CoPP, SSM, Blue Beacon LED, EEE, SPAN, EEM, PIM, FHS, PVLAN support, Superior QoS, CIR |
| Expansion / Connectivity | |
| Interfaces | 48 x 1000Base-T RJ-45 PoE+4 x 10GBase-X SFP+ |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - advance parts replacement - lifetime - response time: next business day |
| Miscellaneous | |
| MTBF | 346,270 hours |
| Compliant Standards | Plug and Play, CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, AS/NZS 60950-1, ICES-003 Class A, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, AES-128, RoHS, CNS 13438, EN 55022 Class A, EN 300 386, KN32, KN35, EN 55032 Class A, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, TCVN 7189 Class A, V-3 Class A, TCVN 7317 |
| Power | |
| Max Supported Qty | 2 |
| Voltage Required | AC 100-240 V |
| Power Device | Internal power supply (not installed) |
| Dimensions & Weight | |
| Width | 44.5 cm |
| Depth | 4.4 cm |
| Weight | 5.5 kg |
| Height | 28.8 cm |
