HPE MSR3044
HP MSR3044 Router
- Brand
- Hewlett Packard Enterprise
- Product code
- JG405A
- SKU
- 6CX7E1TPLYGV1
- EAN/GTIN
- 886112790486
- Excellent forwarding performance
- Powerful security capacity
- Ideal multi-service platform provides WAN router, Ethernet switch, wireless LAN, 3G/4G WAN, firewall, VPN, and SIP/voice gateway all in one device
- Advanced hardware architecture provides multi-core processors, gigabit switching, and PCIE bus
- External RPS or dual internal power supplies, and internal and external CF cards are offered
- High-performance MIM modules (HMIM) supported
- Open application platform architecture
- Field-programmable gate array (FPGA)
- High-density port connectivity
- Multiple WAN interfaces
- High-density Ethernet access with WAN Gigabit Ethernet and LAN 4- and 9-port Fast Ethernet
- Mobility access with 3G SIC module and 3G/4G USB modems
- Packet storm protection protects against broadcast, multicast, or unicast storms with user-defined thresholds
- 3G/4G LTE access support
- Provides 3G wireless access for primary or backup connectivity via a 3G SIC module certified on various cellular networks; optional carrier 3G/4G LTE USB modems available
- Spanning tree protocol (STP)
- Port mirroring duplicates port traffic (ingress and egress) to a local or remote monitoring port
- VLANs supports up to 4094 VLANS or IEEE 802.1q-based VLANs
€4324.75
(Inc. VAT)
Sold Out
(Delivery 2-4 working days)
| General | |
|---|---|
| Device type | Router |
| Enclosure Type | Desktop, rack-mountable - modular - 2U |
| Connectivity technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Performance | Throughput:up to 3.5 Mbps |
| Capacity | Routing table entries:500000 Forwarding table entries:500000 |
| Network / Transport Protocol | TCP/IP, UDP/IP, L2TP, RSVP, NTP, IPSec, ARP, DHCP |
| Routing Protocol | OSPF, RIP, BGP-4, IS-IS, RIP-2, BGP, IGMPv2, IGMP, VRRP, OSPFv2, PIM-SM, PIM-DM, IGMPv3, GRE, OSPFv3, PIM-SSM, Multiprotocol BGP, MSDP, static IPv4 routing, static IPv6 routing, RIPng, MLDv2, MLD, IS-ISv6, MPLS, Bidirectional Forwarding Detection (BFD) |
| Remote Management Protocol | SNMP 1, SNMP 2, RMON, Telnet, SNMP 3, HTTP, TFTP, SSH, CLI |
| Encryption Algorithm | MD5, TLS |
| Authentication method | RADIUS, TACACS+, Secure Shell v.2 (SSH2), Extensible Authentication Protocol (EAP) |
| Features | Firewall protection, DHCP support, NAT support, VPN support, ARP support, MPLS support, IGMP snooping, Syslog support, port mirroring, IPv6 support, Weighted Fair Queuing (WFQ), Rapid Spanning Tree Protocol (RSTP) support, Virtual Route Redundancy Protocol (VRRP) support, Multiple Spanning Tree Protocol (MSTP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), Committed Access Rate (CAR), MLD snooping, Bidirectional Forwarding Detection (BFD), Unicast Reverse Path Forwarding (URPF), DHCP relay, Dynamic Virtual Private Network (DVPN), Network Quality Analyzer (NQA), Multicast Source Discovery Protocol (MSDP), Multicast Border Gateway Protocol (MBGP) |
| Compliant Standards | IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, CISPR 22 Class A, EN 61000-3-3, EN55024, EN55022 Class A, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, FCC Part 68, EMC, ICES-003 Class A, CS-03, EN 61000-4-5, EN 61000-4-11, RoHS, FCC CFR47 Part 15, EN 61000-4-8, UL 60950-1, IEC 60950-1, EN 60950-1, WEEE, EN 60825-1, AS/NZS 60950, ANSI C63.4-2003, EN 60825-2, CAN/CSA C22.2 No. 60950-1-03, EN 61000-3-2:2006, EN 300 386 |
| Processor | 1 x 1 GHz |
| RAM | 2 GB (installed) / 4 GB (max) - DDR3 SDRAM |
| Flash memory | 256 MB |
| Expansion / Connectivity | |
| Interfaces | 3 x 10Base-T/100Base-TX/1000Base-T - RJ-45 2 x Ethernet 1000 - SFP (mini-GBIC) USB 2.0:2 x 4 pin USB Type A Management:1 x auxiliary Management:1 x USB |
| Expansion slots | 2 (total) / 2 (free) x expansion slot 4 (total) / 4 (free) x High-performance Multifunction Interface Module (HMIM) 4 (total) / 4 (free) x Smart Interface Card (SIC) 1 (total) / 1 (free) x CompactFlash |
| Installed Modules Qty (Max) | 0 (installed) / 10 (max) |
| Power | |
| Power Device | Internal power supply (not installed) |
| Installed Qty | 2 (max) |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 100 Watt |
| Miscellaneous | |
| Rack Mounting Kit | Included |
| MTBF | 82.57 years |
| Dimensions & Weight | |
| Width | 44 cm |
| Depth | 48 cm |
| Height | 8.81 cm |
| Weight | 12.45 kg |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 45 °C |
| Humidity Range Operating | 5 - 90% (non-condensing) |
