HP E8206 v2 zl Swch w Premium SW
- Brand
- Hewlett Packard Enterprise
- Product code
- J9640A
- SKU
- SLAYHTMDWADMQ
- EAN/GTIN
- 885631940969
- Advanced classifier-based QoS
- Layer 4 prioritization
- Traffic prioritization
- Class of Service (CoS)
- Remote intelligent mirroring
- Uni-Directional Link Detection (UDLD)
- Command authorization
- Dual flash images
- Multiple configuration files
- HPE unified core-to-edge features
- High-density port connectivity
- High-speed/capacity architecture
- Selectable queue configurations
- Scalable system design
- Nonstop switching
- Redundant management, fabric, and power
- Server-to-switch distributed trunking
- Redundant, hot-swappable cooling
- Passive system design
- Virtual router redundancy protocol
Description
Advanced classifier-based QoS
Classifies traffic using multiple match criteria based on Layer 2, 3, and 4 information; applies QoS policies such as setting priority level and rate limit to selected traffic on a per-port or per-VLAN basis.
Traffic prioritization
Traffic prioritization allows real-time traffic classification into eight priority levels mapped to eight queues.
Uni-Directional Link Detection (UDLD)
Monitors cable between two switches and shuts down the ports on both ends if the cable is broken, turning the bi-directional link into uni-directional; this prevents network problems such as loops.
Command authorization
Command authorization leverages RADIUS to link a custom list of CLI commands to an individual network administrator's login; also provides an audit trail Friendly port names:allow assignment of descriptive names to ports.
Dual flash images
Dual flash images provides independent primary and secondary operating system files for backup while upgrading or fine-tuning the switch configuration.
HPE Unified Core-to-Edge features
HPE ProVision portfolio-common feature implementation allows faster solution deployment.
Selectable queue configurations
Increase performance by selecting the number of queues and associated memory buffering that best meet the requirements of your network applications.
Scalable system design
Chassis architecture/backplane provides built-in performance capacity/headroom to support next-generation high-density/high-speed connectivity.
Nonstop switching
Nonstop switching improves network availability to better support critical applications such as unified communication and mobility; interface and fabric modules continue switching traffic during failover from active to standby management module.
Server-to-switch distributed trunking
Server-to-switch distributed trunking allows a server to connect to two switches with one logical trunk that consists of multiple physical connections; enables load-balancing and increases resiliency.
Redundant, hot-swappable cooling
Redundant fan design and hot-swappable fan tray provide continuity of operation in case of a single fan failure.
Passive system design
Passive chassis backplane provides system reliability and reduces the impact of component failure.
Virtual router redundancy protocol
Allows groups of two routers to dynamically back each other up to create highly available routed environment.
| General | |
|---|---|
| Device type | Switch - L4 - Managed - with HP E8200 zl Switch Premium License |
| Enclosure Type | Rack-mountable 6U |
| Subtype | 10 Gigabit Ethernet |
| Power over Ethernet (PoE) | PoE |
| Performance | Throughput:up to 369.6 Mpps Switching fabric bandwidth:561.6 Gbps Routing/switching capacity:496.8 Gbps |
| Capacity | Routing tables:10000 MAC addresses:64000 |
| MAC Address Table Size | 10K entries |
| Jumbo Frame Support | Yes |
| Routing Protocol | RIP-1, RIP-2, OSPFv2, IGMPv3, OSPFv3, MLDv2, MLD |
| Remote Management Protocol | SNMP 1, RMON 2, RMON, SNMP 3, SNMP 2c, HTTP, TFTP, XRMON |
| Encryption Algorithm | SSL |
| Authentication method | RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
| Features | Hot swap module replacement, VLAN support, IPv6 support, Virtual Route Redundancy Protocol (VRRP) support, Access Control List (ACL) support, Quality of Service (QoS), MLD snooping, STP Root Guard, Uni-Directional Link Detection (UDLD), sFlow v5 |
| Compliant Standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.3at |
| Processor | 1 x Freescale PowerPC 8540:666 MHz |
| RAM | 256 MB DDR SDRAM |
| Flash memory | 4 MB |
| Expansion / Connectivity | |
| Interfaces | 1 x RJ-45 management 1 x USB Type A |
| Expansion slots | 6 (total) / 6 (free) x Expansion Slot |
| Installed Modules Qty (Max) | 6 (max) |
| Power | |
| Power Device | Internal power supply (not installed) |
| Max Supported Qty | 2 |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Miscellaneous | |
| Compliant Standards | FCC Class A certified, CISPR 22 Class A, CISPR 24, EN 60950, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, VCCI Class A ITE, IEC 60950, EN 61000-3-3, EN55024, EN55022 Class A, UL 60950, CSA 22.2 No. 60950, FCC Part 15 |
| Dimensions & Weight | |
| Width | 44.25 cm |
| Depth | 44.42 cm |
| Height | 26.29 cm |
| Weight | 21.82 kg |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - advance hardware replacement - lifetime - response time:next business day |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 45 °C |
| Humidity Range Operating | 15 - 95% (non-condensing) |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 15 - 95% (non-condensing) |
