Intel Core i3-13100 processor

Intel Core i3 13100 - 3.4 GHz - 4 cores - 8 threads - 12 MB cache - FCLGA1700 Socket - OEM


Brand
Intel
Product Family
Core
Product series
i3
Product code
CM8071505092202
SKU
XB421AHP8F08I
EAN/GTIN
5054444518893
  • Intel® Core™ i3 i3-13100
  • 12 MB Smart Cache LGA 1700
  • Processor cores: 4 64-bit
  • Maximum internal memory supported by processor: 192 GB DDR4-SDRAM, DDR5-SDRAM
  • On-board graphics card Intel UHD Graphics 730
€135.3 (Inc. VAT)
Sold Out
(Delivery 2-4 working days)

Product Info

Intel® Gaussian & Neural Accelerator
Intel® Gaussian & Neural Accelerator (GNA) is an ultra-low power accelerator block designed to run audio and speed-centric AI workloads. Intel® GNA is designed to run audio based neural networks at ultra-low power, while simultaneously relieving the CPU of this workload.

Intel® Deep Learning Boost (Intel® DL Boost)
A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.

Intel® Turbo Boost Technology
Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.

Intel® Hyper-Threading Technology
Intel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.

Intel® Standard Manageability (ISM)
Intel® Standard Manageability is the manageability solution for Intel vPro® Essentials platforms and is a subset of Intel® AMT with out-of-band management over Ethernet and Wi-Fi, but no KVM or new life cycle management features.

Intel® Control-Flow Enforcement Technology
CET - Intel Control-flow Enforcement Technology (CET) helps protect against the misuse of legitimate code snippets through return-oriented programming (ROP) control-flow hijacking attacks.

Processor
Processor manufacturer Intel
Processor generation Intel Core i3-13xxx
Processor model i3-13100
Processor family Intel® Core™ i3
Processor cores 4
Processor socket LGA 1700
Processor threads 8
Processor operating modes 64-bit
Performance cores 4
Processor boost frequency 4.5 GHz
Performance-core boost frequency 4.5 GHz
Performance-core base frequency 3.4 GHz
Processor cache 12 MB
Processor cache type Smart Cache
Box No
Processor base power 60 W
Maximum turbo power 89 W
Bus type DMI4
Maximum number of DMI lanes 8
Memory bandwidth supported by processor (max) 76.8 GB/s
Processor codename Raptor Lake
Processor ARK ID 230575
Memory
Maximum internal memory supported by processor 192 GB
Memory types supported by processor DDR4-SDRAM, DDR5-SDRAM
Memory channels Dual-channel
Memory bandwidth (max) 76.8 GB/s
Graphics
On-board graphics card Yes
Discrete graphics card No
On-board graphics card model Intel UHD Graphics 730
On-board graphics card outputs supported Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
On-board graphics card base frequency 300 MHz
On-board graphics card dynamic frequency (max) 1500 MHz
Number of displays supported (on-board graphics) 4
On-board graphics card DirectX version 12.0
On-board graphics card OpenGL version 4.5
On-board graphics card maximum resolution (DisplayPort) 7680 x 4320 pixels
On-board graphics card maximum resolution (eDP - Integrated Flat Panel) 5120 x 3200 pixels
On-board graphics card maximum resolution (HDMI) 4096 x 2160 pixels
On-board graphics card refresh rate at maximum resolution (DisplayPort) 60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) 120 Hz
On-board graphics card refresh rate at maximum resolution (HDMI) 60 Hz
On-board graphics card ID 0x4692
Discrete graphics card model Not available
Number of execution units 24
Multi-Format Codec Engines 1
Features
Execute Disable Bit Yes
Idle States Yes
Thermal Monitoring Technologies Yes
Market segment Desktop
Use conditions PC/Client/Tablet
Maximum number of PCI Express lanes 20
PCI Express slots version 5.0, 4.0
PCI Express configurations 1x16+1x4, 2x8+1x4
Supported instruction sets SSE4.1, SSE4.2, AVX 2.0
Scalability 1S
CPU configuration (max) 1
Embedded options available Yes
Direct Media Interface (DMI) Revision 4.0
Export Control Classification Number (ECCN) 5A992C
Commodity Classification Automated Tracking System (CCATS) 740.17B1
Processor special features
Intel® Hyper Threading Technology (Intel® HT Technology) Yes
Intel® Turbo Boost Technology 2.0
Intel® Quick Sync Video Technology Yes
Intel® Clear Video HD Technology (Intel® CVT HD) Yes
Intel® AES New Instructions (Intel® AES-NI) Yes
Enhanced Intel SpeedStep Technology Yes
Intel® Speed Shift Technology Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 Yes
Intel® Control-flow Enforcement Technology (CET) Yes
Intel® Thread Director No
Intel VT-x with Extended Page Tables (EPT) Yes
Intel® Secure Key Yes
Intel® OS Guard Yes
Intel 64 Yes
Intel Virtualization Technology (VT-x) Yes
Intel Virtualization Technology for Directed I/O (VT-d) Yes
Intel Turbo Boost Max Technology 3.0 No
Intel® Boot Guard Yes
Intel® Deep Learning Boost (Intel® DL Boost) Yes
Intel® Volume Management Device (VMD) Yes
Mode-based Execute Control (MBE) Yes
Intel® Standard Manageability (ISM) Yes
Intel® Threat Detection Technology (TDT) Yes
Operational conditions
Tjunction 100 °C
Technical details
OpenCL version 3.0
Launch date Q1'23
Status Launched
Logistics data
Harmonized System (HS) code 8542310001
Packaging data
Package type Retail box
Weight & dimensions
Processor package size 45 x 37.5 mm
Other features
L2 cache 5120 KB
Maximum internal memory 192 GB
Graphics output eDP 1.4b, DP 1.4a, HDMI 2.1
